SLM-5650 Satellite Modem
Front Panel Operation
Select: CONFIG: Remote: Remote: Serial: Interface
If Interface was selected:
M&C Bus Interface:
RS485-4W
Select RS232, RS485-2W (2-wire), or RS485-4W (4-wire), or TTL (Switching)
using the
interoperation with the CRS-311 (1:1) or CRS-300 (1:N) switch.
Local M&C Bus Address:
IMPORTANT
Select: CONFIG: Remote: Remote: Serial: Interface: Baudrate
If Baudrate was selected:
Local M&C Bus Baud Rate:
IMPORTANT
TTL (Switching)
arrow keys, then press [E]. The TTL (Switch) selection enables
0000
When selecting RS-232 the local M&C bus address displays, 0000.
Addressing is not supported by RS-232 or TTL (Switch)because they
are not a multi drop communication standards. If RS-485 is selected,
the display will show address 0001. This address can be changed
using the front panel. The most significant digit is for Comtech EF
Data redundancy switches.
38400 Baud
The only asynchronous character format supported is 8 bits data, No
parity and 1 stop bit.
RS232
RS485-2W
(
E)
4–20
Revision 2
MN/SLM5650.IOM
(
