SLM-5650 Satellite Modem
Ethernet Management
D.5
SNMP Interface
The Simple Network Management Protocol (SNMP) is an application-layer protocol
designed to facilitate the exchange of management information between network devices.
The SLM-5650 SNMP agent supports both SNMPv1 and v2c.
For proper SNMP operation, the SLM-5650 MIB files must be used with the
associated version of the SLM-5650 base modem M&C. Please refer to the SLM-
5650 SW Release Notes for information on the required FW/SW compatibility.
IMPORTANT
D.5.1
Management Information Base (MIB) Files
MIB files are used for SNMP remote management and consist of Object Identifiers
(OID's). Each OID is a node that provides remote management of a particular function. A
MIB file is a tree of nodes that is unique to a particular device.
There are three MIB files associated with the SLM-5650:
MIB File/Name
fw10874-2-.mib
ComtechEFData
MIB file
FW/11187-4D
SLM-5650
FW/11187-5A
SLM-5650
Traps MIB file
These MIB files should be compiled in a MIB Browser or SNMP Network Monitoring
System server.
Note: The SNMP agent supports both "SNMPv1" and "v2c". The "Traps" file only
needs to be compiled if "SNMPv1" traps are to be used.
Description
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data
products and consists of only the following OID:
Name: comtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247
Full
path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFD
ata(6247)
Module: ComtechEFData
MIB file consists of all of the OID's for management of the modem functions
Trap MIB file is provided for SNMPv1 traps common for base modems.
D-4
Revision 1
MN/SLM5650.IOM
