SLM-5650 Satellite Modem
Installation

2.3.1 External Reference, (J1)

The external reference uses a standard 50 Ω, TNC female connector.
TNC Connector
EXT REF

2.3.2 70 / 140 IF Interface Connectors

The 70 / 140 IF use standard 50 Ω, TNC female connectors.
TNC Connector
Rx
Tx

2.3.3 L-Band IF Interface Connectors

The L-Band IF uses standard 50 Ω, Type N female connectors.
Type N Connector
Rx
Tx

2.3.4 Ethernet Remote Control Connector, (J5)

The Ethernet connector is an 8-pin 'RJ-45' type 10/100 Base-T. Remote control of the modem is
provided using SNMP, HTTP or Telnet with this port.
Reference Description
J1 External Reference 1, 5, 10 MHZ
Reference Description
J3 52-88, 104-176 MHz Receive
J11 52-88, 104-176 MHz Transmit
Reference Description
J4 950-2000 MHz Receive
J2 950-2000 MHz Transmit
2–5
Revision 2
MN/SLM5650.IOM
Direction
Input
Direction
Input
Output
Direction
Input
Output
