Comtech EF Data SLM-5650 Installation And Operation Manual page 55

SLM-5650 Satellite Modem
Configuration
Modulation
Type
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
QPSK 7/8
Overhead R-S Code
Word
IESS-308 225,205
IESS-308 225,205
IESS-308 225,205
IESS-308 225,205
IESS-308 225,205
IESS-308 126,112
IESS-308 126,112
IESS-308 126,112
IESS-308 126,112
IESS-308 126,112
IESS-308 126,112
IESS-308 126,112
IESS-308 208,192
IESS-308 208,192
IESS-308 208,192
IESS-308 208,192
IESS-308 208,192
IESS-308 208,192
IESS-308 208,192
3–5
R-S Depth Data Rate
(kbps)
4, 8, 16 6312 4054.743
4, 8, 16 8448 5394.397
4, 8, 16 32064 20205.826
4, 8, 16 34368 26150.843
4, 8, 16 44736 28153.422
4, 8, 16 1544 1088.571
4, 8, 16 2048 1412.571
4, 8, 16 6312 4153.714
4, 8, 16 8448 5526.857
4, 8, 16 32064 20708.571
4, 8, 16 34368 22189.714
4, 8, 16 44736 28854.857
4, 8, 16 1544 1056.405
4, 8, 16 2048 1369.905
4, 8, 16 6312 4022.214
4, 8, 16 8448 5350.857
4, 8, 16 32064 20040.571
4, 8, 16 34368 21473.714
4, 8, 16 44736 27922.857
Revision 2
MN/SLM5650.IOM
Symbol Rate
(ksps)
