2.14 Environmental

Table 41 lists the environmental specifications for the Desktop Boards D865PERC and
D865PESO.
Table 41.

Desktop Board D865PERC/D865PESO Environmental Specifications

Parameter
Temperature
Non-Operating
Operating
Shock
Unpackaged
Packaged
Vibration
Unpackaged
Packaged
Specification
-40 °C to +70 °C
0 °C to +55 °C
50 g trapezoidal waveform
Velocity change of 170 inches/second
Half sine 2 millisecond
Product Weight (pounds)
<20
21-40
41-80
81-100
5 Hz to 20 Hz: 0.01 g² Hz sloping up to 0.02 g² Hz
20 Hz to 500 Hz: 0.02 g² Hz (flat)
10 Hz to 40 Hz: 0.015 g² Hz (flat)
40 Hz to 500 Hz: 0.015 g² Hz sloping down to 0.00015 g² Hz
Free Fall (inches) Velocity Change (inches/sec)
36 167
30 152
24 136
18 118
