Intel D865PERLX Specification page 103

Table 55. Drive Configuration Submenu (continued)
Feature Options
• Disabled (default)
Hard Disk Pre-Delay
• 1 Second
• 2 Seconds
• 3 Seconds
• 4 Seconds
• 5 Seconds
• 6 Seconds
• 9 Seconds
• 12 Seconds
• 15 Seconds
• 21 Seconds
• 30 Seconds
SATA Port-0 Select to display
sub-menu
SATA Port-1 Select to display
sub-menu
PATA Primary Master Select to display
sub-menu
PATA Primary Slave Select to display
sub-menu
PATA Secondary Select to display
Master sub-menu
PATA Secondary Slave Select to display
sub-menu
Description
Specifies the hard disk drive pre-delay.
Reports type of device attached to Serial ATA
connector 0.
Reports type of device attached to Serial ATA
connector 1.
Reports type of connected device on Parallel ATA
(PATA) IDE primary master interface.
Reports type of connected device on Parallel ATA
(PATA) IDE primary slave interface.
Reports type of connected device on Parallel ATA
(PATA) IDE secondary master interface.
Reports type of connected device on Parallel ATA
(PATA) IDE secondary slave interface.
BIOS Setup Program
103
