Table 2. Feature Summary (continued)
BIOS
Instantly Available
PC Technology
Expansion
Capabilities
Hardware Monitor
Subsystem
For information about
The board's compliance level with ACPI, Plug and Play, and SMBIOS

1.2.2 Manufacturing Options

Table 3 describes the manufacturing options on the Desktop Boards D865PERC and D865PESO.
Not every manufacturing option is available in all marketing channels. Please contact your Intel
representative to determine which manufacturing options are available to you.
Table 3.

Manufacturing Options

SCSI Hard Drive
Activity LED
Connector
For information about
Available configurations for the Desktop Boards D865PERC and D865PESO
• Intel/AMI BIOS (resident in the 4 Mbit FWH)
• Support for Advanced Configuration and Power Interface (ACPI), Plug and Play,
and SMBIOS
• Support for PCI Local Bus Specification Revision 2.2
• Suspend to RAM support
• Wake on PCI, RS-232, front panel, PS/2 devices, and USB ports
• D865PERC: Six PCI bus add-in card connectors (SMBus routed to PCI bus
connector 2)
• D865PESO: Three PCI bus add-in card connectors (SMBus routed to PCI bus
connector 2)
• Hardware monitoring and fan control ASIC
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan connectors
• Three fan sense inputs used to monitor fan activity
• Fan speed control
Allows add-in hard drive controller (SCSI or other) to use the same LED as the
onboard IDE controller.
Product Description
Refer to
Section 1.5, page 18
Refer to
Section 1.3, page 17
13
