Sata/Pata Submenus - Intel D865PERLX Specification

Table 56.

SATA/PATA Submenus

Feature Options
Drive Installed No options
• Auto (default)
Type
• User
Maximum Capacity No options
• Disabled
LBA/Large Mode
• Auto (default)
• Disabled
Block Mode
• Auto (default)
PIO Mode Auto (default)
0
1
2
3
4
• Auto (default)
DMA Mode
• SWDMA0
• SWDMA1
• SWDMA2
• MWDMA0
• MWDMA1
• MWDMA2
• UDMA0
• UDMA1
• UDMA2
• Auto (default)
S.M.A.R.T.
• Disabled
• Enabled
Cable Detected No options
Note: If an LS-120 drive is attached to the system, a row entitled ARMD Emulation Type will be displayed in the above
table. The BIOS will always recognize the drive as an ATAPI floppy drive. The ARMD Emulation Type should
always be set to Floppy.
Description
Displays the type of drive installed.
Specifies the IDE configuration mode for IDE devices.
User allows capabilities to be changed.
Auto fills-in capabilities from ATA/ATAPI device.
Displays the drive capacity.
Displays whether automatic translation mode is
enabled for the hard disk.
(This item is read-only unless Type is set to User.)
Displays whether automatic multiple sector data
transfers are enabled.
(This item is read-only unless Type is set to User.)
Sets the PIO mode.
(This item is read-only unless Type is set to User.)
Specifies the DMA mode for the drive.
Auto = Auto-detected
SWDMAn = Single Word DMAn
SWDMAn = Multi Word DMAn
UDMAn = Ultra DMAn
(This item is read-only unless Type is set to User.)
Enables/disables S.M.A.R.T. (Self-Monitoring, Analysis,
and Reporting Technology).
(This item is read-only unless Type is set to User.)
Displays the type of cable connected to the IDE
interface: 40-conductor or 80-conductor (for ATA-100
peripherals).
BIOS Setup Program
105
