4.4.11 Hardware Monitoring

To access this screen, select Advanced on the menu bar and then Hardware Monitoring.
Maintenance
Table 63 represents an example of the hardware monitoring display.
Table 63.

Hardware Monitoring Display

Feature
Processor Zone Temperature
System Zone 1 Temperature
System Zone 2 Temperature
Processor Fan Speed
Rear Fan Speed
Front Fan Speed
+1.5 V in
Vccp
+3.3 V in
+5 V in
+12 V in
Main
Advanced
PCI Configuration
Boot Configuration
Peripheral Configuration
Drive Configuration
Floppy Configuration
Event Log Configuration
Video Configuration
USB Configuration
Chipset Configuration
Fan Control Configuration
Hardware Monitoring
Description
Displays temperature in Celsius and Fahrenheit
Displays temperature in Celsius and Fahrenheit
Displays temperature in Celsius and Fahrenheit
Displays fan speed in RPM
Displays fan speed in RPM
Displays fan speed in RPM
Displays voltage level of +1.5 V in supply
Displays voltage level of Vccp supply
Displays voltage level of +3.3 V in supply
Displays voltage level of +5 V in supply
Displays voltage level of +12 V in supply
Security Power
BIOS Setup Program
Boot Exit
113
