Intel Desktop Board D865PERC/D865PESO Technical Product Specification

4.4.3 Peripheral Configuration Submenu

To access this submenu, select Advanced on the menu bar and then Peripheral Configuration.
Maintenance
The submenu represented in Table 54 is used for configuring computer peripherals.
Table 54.

Peripheral Configuration Submenu

Feature
Serial Port A
Base I/O address
(This feature is present
only when Serial Port A
is set to Enabled)
Interrupt
(This feature is present
only when Serial Port A
is set to Enabled)
100
Main
Advanced
PCI Configuration
Boot Configuration
Peripheral Configuration
Drive Configuration
Floppy Configuration
Event Log Configuration
Video Configuration
USB Configuration
Chipset Configuration
Fan Control Configuration
Hardware Monitoring
Options Description
• Disabled
Configures serial port A.
• Enabled
Auto assigns the first free COM port, normally COM1, the
address 3F8h, and the interrupt IRQ4.
• Auto (default)
An * (asterisk) displayed next to an address indicates a
conflict with another device.
• 3F8 (default)
Specifies the base I/O address for serial port A, if serial port A
is set to Enabled.
• 2F8
• 3E8
• 2E8
• IRQ 3
Specifies the interrupt for serial port A, if serial port A is set to
Enabled.
• IRQ 4
(default)
Security Power Boot Exit
continued
