1 Product Description

What This Chapter Contains
1.1

Board Differences.......................................................................................................11

1.2 Overview ....................................................................................................................12
1.3 Online Support ...........................................................................................................17
1.4 Operating System Support .........................................................................................17
1.5 Design Specifications .................................................................................................18
1.6 Processor ...................................................................................................................21
1.7 System Memory .........................................................................................................22
®
1.8 Intel 865PE Chipset ..................................................................................................29
1.9 I/O Controller ..............................................................................................................32
1.10 Audio Subsystem........................................................................................................34
1.11 LAN Subsystem..........................................................................................................37
1.12 Hardware Management Subsystem............................................................................39
1.13 Power Management ...................................................................................................42
1.1 Board Differences
This TPS describes these Intel
Boards are identical with the exception of the items listed in Table 1.
Table 1.

Summary of Board Differences

D865PERC
D865PESO
✏
NOTE
Most of the illustrations in this document show only the Desktop Board D865PERC. When there
are significant differences between the two Desktop Boards, illustrations of both boards are
provided.
®
Desktop Boards: D865PERC and D865PESO. The Desktop
• ATX Form Factor (11.60 inches by 9.60 inches [294.64 millimeters by
243.84 millimeters])
• Six PCI bus connectors
• microATX Form Factor (9.60 inches by 9.60 inches [243.84 millimeters by
243.84 millimeters])
• Three PCI bus connectors
11
