Resume on Ring enables telephony devices to access the computer when it is in a power-managed
state. The method used depends on the type of telephony device (external or internal).
✏
NOTE
The use of Resume on Ring and Wake from USB technologies from an ACPI state requires an
operating system that provides full ACPI support.
1.13.2.1

Power Connector

ATX12V-, SFX12V-, and TFX12V-compliant power supplies can turn off the system power
through system control. When an ACPI-enabled system receives the correct command, the power
supply removes all non-standby voltages.
When resuming from an AC power failure, the computer returns to the power state it was in before
power was interrupted (on or off). The computer's response can be set using the Last Power State
feature in the BIOS Setup program's Boot menu.
For information about
The location of the power connector
The signal names of the power connector
The BIOS Setup program's Boot menu
The ATX12V, SFX12V, and TFX12V specifications
Product Description
Refer to
Figure 19, page 60
Table 26, page 63
Table 67, page 116
Section 1.5, page 18
45
