Dual Channel Configuration with Dynamic Mode
Channel A - DIMM 0
Example
1
Channel A - DIMM 1
Channel A - DIMM 0
Example
2
Channel A - DIMM 1
Throughput
Level Configuration
Highest Dual Channel with Dynamic Mode
Dual Channel without Dynamic Mode
Single Channel with Dynamic Mode
Lowest Single Channel without Dynamic Mode
Figure 5. Examples of Dual Channel Configuration with Dynamic Mode
(All DIMMs matched)
Intel
82865PE
MCH
Intel
82865PE
MCH
Characteristics
All DIMMs matched
• DIMMs matched from Channel A to Channel B
• DIMMs not matched within channels
Single DIMM or DIMMs matched within a channel
DIMMs not matched
Product Description
Channel B - DIMM 0
Channel B - DIMM 1
Channel B - DIMM 0
Channel B - DIMM 1
OM15985
25
