Table 9.

LAN Connector LED States

LED Color
Left Green
Green
Right
Orange

1.11.3 LAN Subsystem Software

LAN software and drivers are available from Intel's World Wide Web site.
For information about
Obtaining LAN software and drivers

1.12 Hardware Management Subsystem

The hardware management features enable the Desktop Boards to be compatible with the Wired
for Management (WfM) specification. The Desktop Board has several hardware management
features, including the following:
•
Fan monitoring and control (through the hardware monitoring and fan control ASIC)
•
Thermal and voltage monitoring
•
Chassis intrusion detection
For information about
The WfM specification

1.12.1 Hardware Monitoring and Fan Control ASIC

The features of the hardware monitoring and fan control ASIC include:
•
Internal ambient temperature sensor
•
Two remote thermal diode sensors for direct monitoring of processor temperature and ambient
temperature sensing
•
Power supply monitoring of five voltages (+5 V, +12 V, +3.3 VSB, +1.5 V, and +VCCP) to
detect levels above or below acceptable values
•
Thermally monitored closed-loop fan control, for all three fans, that can adjust the fan speed or
switch the fans on or off as needed
•
SMBus interface
For information about
The location of the fan connectors and sensors for thermal monitoring
LED State
Off
On (steady state)
On (brighter and pulsing)
Off
On
On
Condition
LAN link is not established.
LAN link is established.
The computer is communicating with another computer
on the LAN.
10 Mbit/sec data rate is selected.
100 Mbit/sec data rate is selected.
1000 Mbit/sec data rate is selected.
Refer to
Figure 15, page 40
Product Description
Refer to
Section 1.3, page 17
Refer to
Section 1.5, page 18
39
