Chapter 7
Removing Slides from the Rack
Follow these steps if you need to release the outer slide assembly after it is
installed in the rack.
1. Place your finger inside the slide to release the spring tab, as shown in the
example in Figure 7-4.
2. Press in on the spring tab and pull the outer slide assembly toward you at the
front of the rack.
Figure 7-4. Releasing the Outer Slide Assembly
Rack Mounting the HP Netserver (4-Post)
Spring
Tab
67
