Chapter 12
10. Choose the Exit option and save the changes to save the configuration and exit
the Setup Utility.
Spring Latch
Switch 1 Position
Figure 12-1. Configuration Switch Location
Shaded rectangle
represents the
position of the
switch.
Figure 12-2. Configuration Switch Positions
Battery
(Back of Chassis)
Configuration Switch
Not Used (Default = Off)
BIOS Recovery
Clear Password
Clear CMOS
Not Used (Default = Off)
Not Used (Default = Off)
Not Used (Default = Off)
Not Used (Default = Off)
Open = Off
Closed = On
Troubleshooting
109
