Product Information

Chapter Overview

Chapter Overview
This chapter contains the following main sections:

• Product Description

• Front Panel Components
• Rear Panel Components
• Internal Components
• Monitors
• Keyboard and Mouse
• Site Preparation and Installation
Product Description
The HP V J5000 and J7000 workstations are high-performance systems capable of
ISUALIZE
handling the most complex problems in computational analysis, advanced 3-D design, and
electronic circuit design and verification.
The J5000 and J7000 workstations are similar in many ways. However, they differ in their
system boards and power supplies. The J5000 has two PA-8500 microprocessors and eight
memory slots on its system board, and an 830 Watt power supply with no DC/DC converter
units required. In contrast, the J7000 has four PA-8500 microprocessors and sixteen
memory slots on its system board, and a 1,350 Watt power supply with two DC/DC
converter units. A detailed list of both workstations' features is provided in the "Key
Features" subsection on the next page.

Physical Dimensions and Net Weights

Both workstations use a common chassis, which is 17.5 inches (44.5 cm) high
(34.5 cm) wide 21.0 inches (53.3 cm) deep. Both are also rack-mountable, using the
J1458A Rack Mount Kit. Table 1-1 lists the net weights for each workstation.

Table 1-1. Net Weights for the J5000 and J7000 Workstations

Minimum Configuration
Maximum Configuration
NOTE For a list of the environmental and electrical requirements for each
workstation, see the specifications in Appendix A starting on page 144.
12
J5000
74 pounds (34 Kg) 81 pounds (37 Kg)
88 pounds (40 Kg) 96 pounds (44 Kg)
J7000
13.6 inches
Chapter 1
