Product Information
Rear Panel Components
SCSI Connectors
There are two SCSI connectors on the rear panel: one NSE (Narrow Single-Ended) SCSI-2
connector, and one Ultra2 Wide LVD (Low Voltage Differential) SCSI connector. Use the
SCSI connectors to connect external SCSI devices such as hard disk drives, optical disk
drives, DDS-format tape drives, and CD drives.
Consult the documentation that accompanies each SCSI device for specific information
concerning its use. Also see Appendix C, "SCSI Connections," starting on page 155 for
information about connecting SCSI devices to the J5000 and J7000 workstations.
Do not connect NSE SCSI devices to the LVD SCSI connector, or vice versa,
CAUTION
because damage may occur. Currently Hewlett-Packard does not support
mixing NSE and LVD devices on the same SCSI bus.
NOTE When attaching external SCSI devices, be sure to terminate the last device on
each external SCSI bus. (Terminators are included in a small plastic bag
shipped with the workstation.) If there are no external SCSI devices, the
terminators must be installed directly on the connectors on the rear panel.
Audio Connectors
The J5000 and J7000 workstations have audio-input and -output capabilities through
external input and output connectors on the rear panel and through an internal speaker.
The sound is 16-bit, 44 kHz (CD-quality). Figure 1-10 shows the four audio connectors on
the rear panel.

Figure 1-10. Audio Connectors

Microphone In
Headphones Out
Line Out
Line In
The audio connectors are standard stereo audio mini-jacks. Hewlett-Packard recommends
using gold-plated plugs available through audio retailers for best quality recording and
playback through the external connectors. Table 1-5 provides a summary of the audio
electrical specifications.
24 Chapter 1
