2. If you have not locked your hard drives, proceed to step
hard drives, you must unlock them before removing or replacing a drive:
a. Remove the top metal cover. See
CAUTION:
you will damage the hard drive bay.
b. Press down on the unlock lever to unlock the drive. See
NOTE: If the drive bay is not locked, the procedure for installing additional hard
drives can be accomplished without removing the server from the rack and it is not
necessary to remove the top cover. Completion of the procedure does not require locking
the disk bay, replacing the top metal cover, or replacing the server in the rack.
Figure 4-15 Unlocking and Releasing the Disk Drive
3. Squeeze inward on the colored release clip on the hard drive release lever. See
"Removing the Top Metal Cover" (page
If you try to remove a hard drive without unlocking it from the server,
Removing and Replacing Hot-Swap and Hot-Plug Devices
Step 3. If you have locked your
43).
Figure 4-15.
Figure 4-16.
51
