The following table describes the features of the Server Management screen.

Table 11. Server Management Screen Details

®
Intel Compute Module MFS5520VI User Guide
Setup Item Options
Assert NMI on Enabled
SERR
Disabled
Assert NMI on Enabled
PERR
Disabled
Resume on AC Stay Off
Power Loss
Last state
Reset
Clear System Enabled
Event Log
Disabled
FRB-2 Enable Enabled
Disabled
O/S Boot Enabled
Watchdog
Disabled
Timer
O/S Boot Power Off
Watchdog
Reset
Timer Policy
O/S Boot 5 minutes
Watchdog
10 minutes
Timer Timeout
15 minutes
20 minutes
Plug & Play Enabled
BMC Detection
Disabled
Description
On SERR, generate an NMI and log an error.
On PERR, generate an NMI and log an error.
NOTE: This option is only active if the Assert NMI on
SERR option is [Enabled] selected.
Set the compute module action to take on AC power
loss recovery.
[Stay Off] - compute module stays off.
[Last State] - compute module returns to the same
state before the AC power loss.
[Reset] - compute module powers on.
If enabled, this option clears the System Event Log.
All current entries are lost after saving changes and
rebooting the compute module.
NOTE: This option is reset to [Disabled] after a
reboot.
Fault Resilient Boot (FRB).
If enabled, the BIOS programs the BMC watchdog
timer for approximately 6 minutes. If the BIOS does
not complete POST before the timer expires, the
BMC resets the compute module.
BIOS programs the watchdog timer with the timeout
value selected. If the OS does not complete booting
before the timer expires, the BMC resets the compute
module and an error is logged.
Requires OS support or Intel
Software.
If the OS watchdog timer is enabled, this is the
compute module action taken if the watchdog timer
expires.
[Reset] - Compute module performs a reset.
[Power Off] - Compute module powers off.
NOTE: This option is grayed out when O/S Boot
Watchdog Timer is disabled.
If the OS watchdog timer is enabled, this is the
timeout value BIOS will use to configure the
watchdog timer.
NOTE: This option is grayed out when O/S Boot
Watchdog Timer is disabled.
If enabled, BMC will be detectable by OSs which
support plug and play loading of an IPMI driver. Do
not enable if your OS does not support this driver.
®
