The following table describes the features of the Main Setup screen.

Table 5. Main Screen Details

®
Intel Compute Module MFS5520VI User Guide
Setup Item Options
Logged in as
Platform ID
System BIOS
Version
System BIOS
Build Date
Total Memory
Quiet Boot Enabled
Disabled
POST Error Enabled
Pause Disabled
System Date [Day of week
MM/DD/YYYY]
System Time [HH:MM:SS]
Description
Information only. Displays the current BIOS
Setup password level, Administrator or User. If no
passwords are set, Administrator is the default
mode.
Information only. Displays the Platform ID
S5520VI
Information only. Displays the current BIOS
version.
Information only. Displays the current BIOS
build date.
Information only. Displays the total physical
memory installed in the compute module, in MB or
GB. The term physical memory indicates the total
memory discovered in the form of installed
DIMMs.
If Quiet Boot is enabled a logo screen is displayed
during POST. By default, Quiet Boot is enabled in
the BIOS setup. If the logo is displayed during
POST, press <Esc> to hide the logo and display
the diagnostic screen.
If a logo screen is not present in the flash ROM, or
if Quiet Boot is disabled, the summary and
diagnostic screen is displayed during POST.
If enabled, the POST Error Pause option takes the
compute module to the error manager to review
the critical POST errors when they occur. Minor
and fatal error displays are not affected by this
setting.
If disabled the compute module attempts to boot
and does not go to the Error Manager for critical
POST errors.
System Date has configurable fields for Month,
Day, and Year.
Use [Enter] or [Tab] key to select the next field.
Use [+] or [-] key to modify the selected field.
System Time has configurable fields for Hours,
Minutes, and Seconds.
Hours are in 24-hour format.
Use the [Enter] or [Tab] key to select the next field.
Use the [+] or [-] key to modify the selected field.
59
