If Local Application Mode is selected, select Remote Service Mode, reboot the server, and then
o
continue with step 2.
On the server that you want to configure, connect to the Systems Insight Manager server (port: 280),
2.
and then log in.
Select Device Queries.
3.
Under Device by Type, select All Servers.
4.
Connect to the server that is running ACU.
5.
Under Device Links, select System Management Homepage.
6.
The login screen for the System Management Homepage opens.
Log in using your credentials:
7.
If you are using version 2.0.0 or later of the System Management Homepage, use your
o
operating system user name and password.
If you are using an earlier version of the System Management Homepage, use your WBEM user
o
name and password.
The System Management Homepage opens.
For more information about the System Management Homepage, see the following:
The HP System Management Homepage web page
o
(http://h18013.www1.hp.com/products/servers/management/agents/index.html)
The HP System Management Homepage Installation Guide on the HP website
o
(http://www.hp.com)
Click Array Configuration Utility on the left side of the screen.
8.
ACU opens, scans the remote server, and detects controllers. This process can last up to 2 minutes.
When controller detection is complete, the controllers are available on the Controller/Device menu.
Select a controller from the Controller/Device menu.
9.
HP Array Configuration Utility 25
