RAID 60
RAID 60 is a nested RAID method in which the constituent hard drives are organized into several identical
RAID 6 logical drive sets (parity groups). The smallest possible RAID 60 configuration has eight drives
organized into two parity groups of four drives each.
For any given number of hard drives, data loss is least likely to occur when the drives are arranged into
the configuration that has the largest possible number of parity groups. For example, five parity groups of
four drives are more secure than four parity groups of five drives. However, less data can be stored on
the array with the larger number of parity groups.
RAID 60 is particularly useful for data archives and high-availability solutions.
Advantages:
•
Higher performance than for RAID 6, especially during writes.
•
Better fault tolerance than either RAID 0 or RAID 6.
•
Up to 2n physical drives can fail (where n is the number of parity groups) without loss of data, as
long as no more than two failed drives are in the same parity group.
Disadvantages:
•
All data is lost if a third drive in a parity group fails before one of the other failed drives in the parity
group has finished rebuilding.
•
A greater percentage of array capacity is used to store redundant or parity data than with non-
nested RAID methods.
Comparing the hardware-based RAID methods
NOTE:
Not all controllers support RAID 6 (ADG).
Drive arrays and fault-tolerance methods 102
