Menu option
Controller
Settings
Create New
Array
Array Options menu (appears in the secondary panel when an array is highlighted in the Logical
Configuration View panel)
Menu option
Expand Array
Assign Spare
Remove Spare
Delete Entire
Array
Logical Drive Options menu (appears in the secondary panel when a logical drive is highlighted in
the Logical Configuration View panel)
Menu option
Delete
Drive Settings
SSP Settings*
*This menu option is available only with the MSA1000 and MSA1500.

Typical manual configuration procedures

This section describes the procedures for the following common tasks:
Result of selecting the option
A new panel opens, displaying settings for three
options: Rebuild Priority, Expand Priority, and
Accelerator Ratio.
Three panels open:
Create Array (displays a menu with the following
options: Assign Drive, Assign Spare, Remove Drive,
and Accept Changes)
Physical Drives (lists the spare drives and
unassigned physical drives that are connected to
the controller)
New Array (shows the updated physical
configuration view)
Result of selecting the option
Three panels open:
Expand Array (displays a menu with the following
options: Assign Drive, Remove Spare, and Accept
Changes)
Physical Drives (lists the spare drives and
unassigned physical drives that are connected to
the controller)
Expand Existing Array (shows the updated physical
configuration view)
A new panel opens, displaying a menu of the valid
drives.
A new panel opens, displaying the spares.
The data and all the logical drive structures on the
array are deleted.
Result of selecting the option
The data and the logical drive structure on the array
are deleted.
A new panel opens, displaying settings for two
options: Fault Tolerance and Stripe Size.
A new panel opens, displaying the Enable or Disable
option.
HP Online Array Configuration Utility for NetWare 16
