802.1x statistics

Use the following command to display the 802.1x authenticator statistics of the selected port:
show interface port <port number> dot1x counters
Command mode: All
Authenticator Statistics:
eapolFramesRx
eapolFramesTx
eapolStartFramesRx
eapolLogoffFramesRx
eapolRespIdFramesRx
eapolRespFramesRx
eapolReqIdFramesTx
eapolReqFramesTx
invalidEapolFramesRx
eapLengthErrorFramesRx = 0
lastEapolFrameVersion
lastEapolFrameSource
Authenticator Diagnostics:
authEntersConnecting
authEapLogoffsWhileConnecting
authEntersAuthenticating
authSuccessesWhileAuthenticating
authTimeoutsWhileAuthenticating
authFailWhileAuthenticating
authReauthsWhileAuthenticating
authEapStartsWhileAuthenticating
authEapLogoffWhileAuthenticating
authReauthsWhileAuthenticated
authEapStartsWhileAuthenticated
authEapLogoffWhileAuthenticated
backendResponses
backendAccessChallenges
backendOtherRequestsToSupplicant
backendNonNakResponsesFromSupplicant = 0
backendAuthSuccesses
backendAuthFails
The following table describes the 802.1x authenticator diagnostics for a selected port:
Table 45 802.1x statistics for port
Statistics
Authenticator Diagnostics
authEntersConnecting
authEapLogoffsWhileConnecting
authEntersAuthenticating
authSuccessesWhile
Authenticating
authTimeoutsWhileAuthenticating
authFailWhileAuthenticating
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 00:00:00:00:00:00
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
= 0
Description
Total number of times that the state machine transitions to the
CONNECTING state from any other state.
Total number of times that the state machine transitions from
CONNECTING to DISCONNECTED as a result of receiving an EAPOL-
Logoff message.
Total number of times that the state machine transitions from
CONNECTING to AUTHENTICATING, as a result of an EAPResponse/
Identity message being received from the Supplicant.
Total number of times that the state machine transitions from
AUTHENTICATING to AUTHENTICATED, as a result of the Backend
Authentication state machine indicating successful authentication of the
Supplicant.
Total number of times that the state machine transitions from
AUTHENTICATING to ABORTING, as a result of the Backend
Authentication state machine indicating authentication timeout.
Total number of times that the state machine transitions from
AUTHENTICATING to HELD, as a result of the Backend Authentication
state machine indicating authentication failure.
