ISCLI Reference
Introduction
The HP GbE2c Ethernet Blade switch is ready to perform basic switching functions right out of the box. Some of the
more advanced features, however, require some administrative configuration before they can be used effectively. This
guide provides a command reference for the HP GbE2c Ethernet Blade Switch and the HP GbE2c Layer 2/3 Ethernet
Blade Switch.
The extensive switching software included in the switch provides a variety of options for accessing and configuring
the switch:
Text-based command line interfaces (AOS CLI and ISCLI) for access via a local terminal or remote Telnet/Secure
Shell (SSH) session
Simple Network Management Protocol (SNMP) support for access through network management software such
as HP Systems Insight Manager
A browser-based management interface for interactive network access through a Web browser
The ISCLI provides a direct method for collecting switch information and performing switch configuration. Use a basic
terminal to view information and statistics about the switch, and to perform any necessary configuration.
This chapter explains how to access the ISCLI to the switch.

Additional references

Additional information about installing and configuring the switch is available in the following guides, which are
available at http://www.hp.com/go/bladesystem/documentation.
HP GbE2c Ethernet Blade Switch for c-Class BladeSystem User Guide
HP GbE2c Ethernet Blade Switch for c-Class BladeSystem Command Reference Guide
HP GbE2c Ethernet Blade Switch for c-Class BladeSystem Application Guide
HP GbE2c Ethernet Blade Switch for c-Class BladeSystem Browser-based Interface Reference Guide
HP GbE2c Ethernet Blade Switch for c-Class BladeSystem Quick Setup Instructions

Connecting to the switch

You can access the command line interface in one of the following ways:
Using a console connection via the console port
Using a Telnet connection over the network
Using a Secure Shell (SSH) connection to securely log in over a network

Establishing a console connection

To establish a console connection with the switch, you need:
A null modem cable with a female DB-9 connector (See the HP GbE2c Ethernet Blade Switch for c-Class
BladeSystem User Guide for more information.)
An ASCII terminal or a computer running terminal emulation software set to the parameters shown in the table
below
Table 1 Console configuration parameters
Parameter
Baud Rate
Data Bits
Parity
Stop Bits
Flow Control
Value
9600
8
None
1
None
