Layer 2 IP Trunk Hash configuration

Trunk hash parameters are set globally for the GbE2c Ethernet Blade switch. You can enable one or two parameters,
to configure any of the following valid combinations:
SMAC (source MAC only)
DMAC (destination MAC only)
SIP (source IP only)
DIP (destination IP only)
SIP + DIP (source IP and destination IP)
SMAC + DMAC (source MAC and destination MAC)
The following table describes the IP Trunk Hash Configuration commands.
Table 113 IP Trunk Hash Set commands
Command
portchannel hash source-mac-
address
portchannel hash destination-
mac-address
portchannel hash source-ip-
address
portchannel hash destination-ip-
address
portchannel hash source-
destination-ip
portchannel hash source-
destination-mac
show portchannel hash

Link Aggregation Control Protocol configuration

The following table describes the LACP Configuration commands.
Table 114 LACP Configuration commands
Command
lacp system-priority {<1-65535>}
lacp timeout {short|long}
NOTE: HP recommends that you use a timeout value of
utilization rate remains at 100% for periods of 90 seconds or more, consider using static trunks instead of LACP.
show lacp
Description
Enable or disable trunk hashing on the source MAC.
Command mode: Global configuration
Enable or disable trunk hashing on the destination MAC.
Command mode: Global configuration
Enable or disable trunk hashing on the source IP.
Command mode: Global configuration
Enable or disable trunk hashing on the destination IP.
Command mode: Global configuration
Enable trunk hashing on the source and destination IP.
Command mode: Global configuration
Enable trunk hashing on the source and destination MAC address.
Command mode: Global configuration
Display current trunk hash configuration.
Command mode: All
Description
Defines the priority value (1 through 65535) for the switch. Lower
numbers provide higher priority. The default value is 32768.
Command mode: Global configuration
Defines the timeout period before invalidating LACP data from a remote
partner. Choose (3 seconds) or
short
value is .
long
Command mode: Global configuration
, to reduce LACPDU processing. If your switch's CPU
long
Display current LACP configuration.
Command mode: All
(90 seconds). The default
long
Configuration Commands 108
