Page 30
Set the detection area (marked in yellow).
Set the minimum and maximum face size in the frame. (Marked in blue). Notice that the
blue face sketch is reference only. Its position is not changing any setting.
If required, you can switch to the
"Blocked Area" tab and set areas where
the camera shouldn't look for license
plates.
License exposure gives more weight to the face detection area when setting the auto exposure.
4.4.3 Analytics and Live Display.
Once enabled, the Analytics will appear on the camera's live interface. It will only appear on
Ossia devices running v1.4.3 if configured so.
4.5 Network Configuration
Network configuration includes eight submenus: Port, IP Address, Server Configuration, IP
Notify, DDNS Config, RTSP, UPnP, Mail Setting, and FTP.
4.5.1 TCP/IP
Go to "Network"
IPv4 Protocol. There are two options for IP setup: obtain an IP address automatically by
DHCP or a defined IP address. You may choose one of the options as required.
Automatic IP Assignment: Use "Obtain an IP address automatically" for the camera to
communicate with an available DHCP server that will assign the camera with an IP address
"TCP IP" tab to see the interface shown below. The first and default tab is
IP CAMERA USER MANUAL
