The video parameters are as follows:
Parameter
Record stream
Pre-recording time
Cycle recording
Below are the schedule settings. Enable the schedule if required and set the recording time for
each of the weekdays. You can also set a holiday schedule and add required dates to it.
The next tab is "Snapshot"
The snapshot parameters are as follows:
Parameter
Image Format
Resolution
Image quality
Snapshot Interval
Snapshot Quantity
Scheduled snapshots
IP CAMERA USER MANUAL
Which video stream will be used for record
The duration of video prior to the recording trigger
Weather to recycle record or stop when the SD card is
full
Click on it to set the snapshot parameters and schedule.
The image format is JPEG
Set the snapshot resolution
The quality of the image reflects on its size.
The duration between two snapshots
The total number of snapshots to be taken after a trigger
Taking a snapshot according to a specified schedule
Meaning
Meaning
