Page 14
The display parameters are as follows:
Parameter
Config file*
Brightness
Contrast
Hue
Saturation
Sharpness
Noise reduction
Defog
Auto-Iris
BLC
Level
HFR
Smart-IR
White Balance
Frequency
Day/Night Mode*
Sensitivity
Delay Time
Infra-Red Mode
Shutter Mode
Max
Min
Gain Mode
Gain Limit
Corridor Pattern
Image Mirror
Image Flip
*If you set the day/night mode to schedule or you wish to differentiate between the daytime
and night-time image settings, you will need to set the schedule accordingly.
Click on the "Schedule" tab and set the schedule as you wish.
IP CAMERA USER MANUAL
You can set an individual configuration for Day and night.
Common is used for both
Set the image brightness
Set the image contrast
Set the image hue
Set the image saturation
Enable/Disable the sharpness and set its level
Enable/Disable the 3D-DNR and set its level
Enable/Disable the defog and set its level
Set the lens to Auto-Iris mode (Not suitable for fixed iris models).
Set HLC/BLC/True-WDR to deal with advanced light conditions.
The Level of the HWDR/BLC/HLC
Switch the camera to work in 50/60FPS instead of 25/30FPS.
(Disables True WDR).
Enable Smart IR function that prevents burnt pixels due to strong
IR illumination.
Set the white balance of the camera
Set the frequency to 50/60Hz
Set the day/night mode (Auto/Day/Night/Schedule)
The light sensor sensitivity
The delay time before switching day/night modes
Set the IR status
Set the camera digital Shutter (Auto/Manual)
The maximum shutter speed
The minimum shutter speed
Set the camera Gain (Auto/Manual)
Set the Gain value
Rotate the image to fit corridors
Mirror the image horizontally
Flip the image vertically
Meaning
