Page 19
4.3 Alarm Configuration
Alarm configuration includes four submenus: Motion Detection, General Fault, Alarm in and
Alarm Out.
4.3.1 Motion Detection
Go to "Alarm configuration"→ "Motion Detection" to see an interface as below.
The first tab is the "Alarm Config". Enable or disable the alarm and set the alarm holding
time. The holding time means that the alarm signal will stay active and no additional alarms
will be generated during that time.
Choose the camera's response to the alarm:
Alarm Out
Trigger Snap
Trigger SD Recording
Trigger Email
Trigger FTP
Next is the "Area and Sensitivity" Tab. Move the "Sensitivity" scroll bar to set up the motion
sensitivity and click on "draw" to enable the marking on the image. Note that you can set
different sensitivities to a different area of the picture as shown below. Once finished, click on
"Stop Draw".
IP CAMERA USER MANUAL
Alarm Triggers:
triggers the alarm out relay
takes a snapshot (SD card must be available)
Initiates video recording over the SD card (SD card
must be available)
sends an email as configured in the Email section.
send a snapshot as configured in the FTP section
