Page 25
4.3.4 Alarm Out
The Alarm output is actually a relay that can operate many types of devices such as gates,
doors, strobe light, and sirens. The alarm out always works in a "NO" mode (Normally open)
which means that the relay is open in a normal state and closed in an armed state.
1. Go to "Alarm"→ "Alarm Out" to get to the interface as shown below:
2. Alarm out has 4 modes as described below:
A. Alarm Linkage (Shown Above): This mode will set the alarm out to be triggered as
a response to any of the available alarms (Motion, Alarm in, Analytics). If this
mode is chosen you will need to set it properly.
Parameter
Alarm Out Name
Alarm Holding Time
B.
Manual Mode: This mode will enable you to manually operate the relay.
C.
Day/night switch linkage: This mode allows you to set the relay condition according
to the day/night mode of the camera.
D. Schedule mode: This mode allows you to set the relay condition according to a
IP CAMERA USER MANUAL
Meaning
You can set a unique name for easy identification.
The holding time means that the alarm signal will stay
active and no additional alarms will be generated
during that time.
