Page 17
IP CAMERA USER MANUAL
4.2.4 Video Mask
You can set 4 mask areas at most.
To set up video mask
1. Enable video mask.
2. Click "Draw" button and then drag the mouse to draw the video mask area.
3. Click "Save" button to save the settings.
4. Return to the live to see the following picture.
To clear the video mask:
Go to video mask menu and then click "Clear" button to delete the current video mask area.
4.2.5 ROI Configuration
ROI is used to allocate higher bit-rate on a certain area of the image than other areas
To set up ROI
1.
Go to Config→ROI menu.
