6.5 EtherCAT Master X1
Specification
Connection
8
1
Fig. 15: RJ45 socket front view
6.6 Ethernet X2
Specification
Connection
8
1
Fig. 16: RJ45 socket front view
ma_ca_c6-compact3-inst-20372037_en
Fieldbus type
Socket
Transmission level
Transmission speed
Transmission medium
Potential separation
PIN
1
2
3
4
5
6
7
8
Tab. 3: PIN assignment RJ45 EtherCAT
LED / light pattern
Yellow
Green
Off
On
Flicker
Tab. 4: Function of the LEDs
Fieldbus type
Socket
Transmission level
Transmission speed
Transmission medium
Potential separation
PIN
1
2
3
4
5
Electrical installation | 6
EtherCAT®
X1 RJ45
100Base-Tx according to IEEE802.3
with
autonegotiation
and auto-crossover
100 Mbit/s
Twisted Pair S-UTP; Cat. 5
maximum cable length 100 m
Functional isolation to the control poten-
tial.
RJ45 without supply voltage
(Viewing with Auto-Cross Over)
TX+
TX-
RX+
Reserved
Reserved
RX-
GND
GND
Function
without function
Link/Activity
Port closed
Port open; no data traffic
Port open; with data traffic
Ethernet
X2 RJ45
100Base-Tx according to IEEE802.3
with
autonegotiation
and auto-crossover
10/100 Mbit/s
Twisted Pair S-UTP; Cat. 5
maximum cable length 100 m
Functional isolation to the control poten-
tial.
RJ45 without supply voltage
(Viewing with Auto-Cross Over)
TX+
TX-
RX+
reserved
reserved
RX+
RX-
TX+
TX-
RX+
RX-
TX+
33
