3.6.3.1 Model 1, 2 and 3
3.6.3.2 Model 4
ma_ca_c6-compact3-inst-20372037_en
ohne
Feldbusschnittstellen
Lüftungsschlitze
Fig. 7: C6 COMPACT 3 bottom Model 1, 2 and 3
X11 INTERBUS OUT
D-Sub DE9 female
X10 INTERBUS IN
D-Sub DE9 male
Fig. 8: C6 COMPACT 3 bottom Model 4
Product description | 3
