5.2 Dimensions
5.3 Mounting direction
ma_ca_c6-compact3-inst-20372037_en
132,6 mm
139,2 mm
Fig. 11: Dimensions COMPACT 3
The following mounting orientations are possible without derating:
• typical for control cabinets (mounting rail horizontally on the wall).
Assembly | 5
139,2 mm
25 mm
27
