- Page 1 COMBISTOP TYPE 28 INSTRUCTIONS FOR USE | INSTALLATION Translation of the original manual Document 20193433 EN 02...
-
Page 3: Preface
PrEfAcE Preface The described hard- and software are developments of the KEB Automation KG. The enclosed documents correspond to conditions valid at printing. Misprint, mistakes and technical changes reserved. Signal words and symbols Certain operations can cause hazards during the installation, operation or thereafter. -
Page 4: Laws And Guidelines
If applicable, the license terms of this software are contained in the instructions for use. The instructions for use are already available to you, can be downloaded free of charge from the KEB website or can be requested from the respec- tive KEB contact person. -
Page 5: Table Of Contents
3.1.1 Climatic environmental conditions ..................18 3.1.2 Mechanical environmental conditions ................18 3.1.3 Electrical operating conditions .................... 18 3.2 Device data cOMbISTOP 28 ......................19 3.2.1 Overview ..........................19 3.3 Dimensions and weights ......................20 3.3.1 Version without options ...................... 20... - Page 6 TAbLE Of cONTENTS 3.3.3 Version with hand release ....................22 3.3.4 Version for tachometer ....................... 23 4 Mounting ............... 24 4.1 Notes on mounting ........................24 4.2 Mounting the brake ........................25 4.3 Micro switch (option) ........................27 4.3.1 Micro switch as anchor position monitoring (default) ............27 4.3.1.1 Checking the micro switch setting for anchor position monitoring ........
-
Page 7: List Of Figures
LIST Of fIGUrES 10 Dismounting and Disposal ........40 10.1 Dismounting ..........................40 10.2 Disposal ............................40 11 Certification ..............41 11.1 EU Declaration of conformity ..................... 41 11.2 CSA Certificat ..........................43 12 revision History ............46 List of figures Figure 1: Parts list COMBISTOP Type 28 .................. -
Page 8: Glossary
Functional earth Reference potential, ground International standard IP xx Degree of protection (xx for level) KEB product The KEB product is subject of this manual. Manufacturer The manufacturer is KEB, unless otherwise specified (e.g. as ma- nufacturer of machines, engines, vehicles or adhesives). -
Page 9: Standards For Mechanical Components
STANDArDS fOr MEcHANIcAL cOMPONENTS Standards for mechanical components VDE 0580 Electro magnetic devices and components DGUV regulation 3 Electrical installations and equipment DIN 46228-1 Tubular end-sleeves without plastic sleeve DIN 46228-4 Tubular end-sleeves with plastic sleeve DIN IEC 60364-5-54 Low-voltage electrical installations - Part 5-54: Selection and erection of electrical equipment - Earthing arrangements, protective conductors and protec- tive bonding conductors EN 60204-1... -
Page 10: Basic Safety Instructions
► Read the instructions for use ! ► Observe the safety and warning instructions ! ► If anything is unclear, please contact KEB ! 1.1 Target group This manual is determined exclusively for technical staff. Technical staff for the purpose of this manual must have the following qualifications: •... -
Page 11: Installation And Mounting
bASIc SAfETY INSTrUcTIONS 1.3 Installation and mounting NOTICE Squeezing and pinching of fingers by self-rotation. ► Before installation, make sure that the drive is load-free. ► Secure drive against rotation. Consider the following installation measures to prevent faults ► Do not operate the brake in an explosive environment. ►... -
Page 12: Start-Up And Operation
bASIc SAfETY INSTrUcTIONS 1.5 Start-up and operation The operation must not be started until it is determined that the installation complies with the machine directive; Account is to be taken of 60204-1. Pay attention to friction work (speed and the frequency of opera- cAUTION tion) ! Loss or drop of the braking torque ! -
Page 13: Maintenance
► Infringement will annul the liability for resulting consequences. 1.7 Disposal Electronic devices of the KEB Automation KG are exclusively professional devices for further industrial processing (so-called B2B devices). Manufacturers of B2B devices are obliged to take back and recycle devices manufac- tured after 14.08.2018. -
Page 14: Product Description
Any use beyond the technical specifications is also considered as not specified. The actual use of the brake in the target products is beyond KEB Automation KG's con- trol and, therefore, shall be exclusively within the operating company's responsibility. -
Page 15: Type Code
PrODUcT DEScrIPTION 2.4 Type code The type designation and the version can be found on the nameplate or on the marking. x x 2 8 G x x - x x x x Version Customer versions completely closed Housing for tacho mounting W: Shaft sealing ring 1: without hand release hand release... -
Page 16: Overview/Parts List
PrODUcT DEScrIPTION 2.5 Overview/Parts List Size 02 to 06 Seal ring Size 07 to Magnetic system Lining Magnet Flange (optional) Adjusting spacer Seal ring Armature Hand release (optional) Figure 1: Parts list COMBISTOP Type 28 2.6 functional description The braking force is generated in de-energised state by pressure springs which press the armature and the lining against the friction surfaces. -
Page 17: Options
PrODUcT DEScrIPTION 2.7 Options 2.7.1 Micro switch • A micro switch can only be retrofitted if the brake is prepared for it. For this reason, the variant must be ordered ex works. • Protection class IP65 is no longer given if the brake is equipped with a micro switch! A micro switch can be used to monitor the switching state of the armature (brake open/ closed). -
Page 18: Technical Data
3 Technical Data 3.1 Operating conditions 3.1.1 climatic environmental conditions Storage Standard class Notes Ambient temperature EN 60721-3-1 -25…55 °C Relative humidity <50 % (without condensation) Storage height – – Max. 3000 m above lea level Transport Standard class Notes Ambient temperature EN 60721-3-2 -25…60 °C... -
Page 19: Device Data Combistop 28
DEvIcE DATA cOMbISTOP 28 3.2 Device data cOMbISTOP 28 3.2.1 Overview Unit size Rated torque after run in / Nm Rated power Rated voltage 24 / 105 / 180 / 205 N_dc Cyclic duration factor ED / % Speed for service braking 3000 3000 3000 3000 3000 3000 3000 1500 Max. -
Page 20: Dimensions And Weights
DIMENSIONS AND WEIGHTS 3.3 Dimensions and weights 3.3.1 version without options 07…0928G10-xxxx 02…0628G10-xxxx Dimensions / mm Weight / kg Size 28.G1 28.G2 max. 72 15** 1-1,5 88x3 118 90 2-2,5 42,8 41,8 110x3 143 112 2-2,5 52,8 51,8 132x3 61,5 0,2 165 132 30 2,5-3 58,3 57,3 152x3... -
Page 21: Version For/With Shaft Sealing Ring
DIMENSIONS AND WEIGHTS 3.3.2 version for/with shaft sealing ring for shaft sealing ring with shaft sealing ring Dimensions / mm Size Figure 4: Dimensions COMBISTOP Type 28 shaft sealing ring... -
Page 22: Version With Hand Release
DIMENSIONS AND WEIGHTS 3.3.3 version with hand release 02-05/0728G2x-xxxx 06/0828G2x-xxxx 0928G2x-xxxx Dimensions / mm Size 105,5 53,5 15,5 500 +15/-5 18,5 500 +15/-5 25,5 500 +15/-5 30,5 500 +15/-5 500 +15/-5 750 ±15 76,3 750 ±15 69,5 750 ±15 Figure 5: Dimensions COMBISTOP Type 28 hand release... -
Page 23: Version For Tachometer
DIMENSIONS AND WEIGHTS 3.3.4 version for tachometer xx28GxT-xxxx Dimensions / mm Size 41,8 51,8 57,3 67,8 73,2 85,5 Figure 6: Dimensions COMBISTOP Type 28 tachometer... -
Page 24: Mounting
► The movement of the armature must not be impeded by the ingress of foreign parti- cles into the air gap. Take appropriate safety measures as required. ► The eccentricity of the mounting hole circle relative to the shaft end must not ex- ceed the following values: COMBISTOP 28 03…06 07…09 Eccentricity / mm ►... -
Page 25: Mounting The Brake
MOUNTING 4.2 Mounting the brake ATTENTION If no suitable friction surface is available. ► Install the optional flange (4) on the motor bearing assembly. Step 1: Installing the hub Install the hub (2) on the motor shaft, then secure the hub on the motor shaft axially. The hub and the linings must not be dam- aged! Make sure that the hub cannot run against the second friction surface. - Page 26 MOUNTING Step 2: Mounting the lining Slide the lining (3) onto the hub. While doing so, be careful not to damage the lining by misaligned or tilted position- ing. The lining must be easily movable on the hub! Step 3: Mounting the magnetic system Slide the fully assembled magnetic sys- tem (1) over the hub and the lining.
-
Page 27: Micro Switch (Option)
MOUNTING 4.3 Micro switch (option) The micro switch can be used for anchor position monitoring or as wear monitoring. 4.3.1 Micro switch as anchor position monitoring (default) A micro switch can be used to monitor the switching state of the armature (brake open/ closed). -
Page 28: Replacing The Micro Switch
MOUNTING 4.3.3.1 Replacing the micro switch cAUTION Loss of braking efficiency ! Before replacing the micro switch, mechanically secure the load against unintended movements and disconnect the brake from load! Micro switch hexagon head screw Socket head screw hexagon nut disc Figure 7: Replacing the micro switch... -
Page 29: Readjusting The Micro Switch
MOUNTING 4.3.3.2 Readjusting the micro switch cAUTION Loss of braking efficiency! Before checking the micro switch settings, mechanically secure the load against unintended movements and disconnect the brake from load! ► Loosen the hexagon nut (5). ► Turn the hexagon head screw (4) towards the micro switch (1) until it contacts the micro switch tappet. -
Page 30: Electrical Connection
► Compare with existing voltage source. ► The maximum input voltage Uin must not be exceeded. ► Only connect if the values match. If no suitable DC voltage is available, the following KEB accessories can be used: • Half-wave and bridge rectifiers (COMBITRON 91) •... -
Page 31: Ac Side Switching
ELEcTrIcAL cONNEcTION NOTICE connection at inverter operation. ► Rectifiers or power boxes are destroyed when operated at drive converters. ► Rectifiers or power boxes may only be connected directly to the mains. Influence on the connection time! The brake can be switched off on the DC side or on the AC side. Switching off on the DC side reduces the connection time, i.e. the period of time until the torque is reached to decelerate. -
Page 32: Dc Side Switching
ELEcTrIcAL cONNEcTION 5.1.2 Dc Side Switching Switching occurs between rectifier and brake. KEB rectifiers and power boxes are pro- tected against voltage peaks occurring during switching. ► Not suitable for inverter operation since the powerbox or rectifier would be destroyed. Figure 12: Connection for DC side switching 5.1.3 Dc and Ac current switching ► Inverter operation possible because the powerbox or rectifier is supplied by the mains. -
Page 33: Start-Up
INSPEcTIONS PrIOr TO STArT-UP Of THE brAKE 6 Start-up 6.1 Inspections prior to start-up of the brake Visual inspection • Do connection and rated voltage (nameplate) agree? • Are external damages visible? • Are there impurities in the functional area or foreign bodies in the air gap of the brake? Load-free testing •... -
Page 34: Operation
OPErATION 7 Operation The brake is switched via the voltage supply (=> connection). The max. number of switching cycles (=> „3.2 Device data COMBISTOP 28“) must not be exceeded. 7.1 Hand release (option) As an option, the brake can be deliver with a hand release In the event of malfunctions, the brake can be actuated using the hand release. -
Page 35: Troubleshooting
Magnet coil or connecting Replace the brake. cable defective excessive heating Install a high-speed circuit breaker (for example, KEB Pow- erbox). no braking function Damaged teeth impede Replace the lining and the hub. movement of armature... -
Page 36: Maintenance And Service
MAINTENANcE AND SErvIcE 9 Maintenance and Service • Observe the general safety instructions. • The brake must not be under voltage during maintenance and repair work! • Protect electrical and electronic components from splash water. 9.1 Maintenance intervals Due to the design, the brake COMBISTOP Type 28 can only be checked when it is removed. -
Page 37: Check Air Gap
MAINTENANcE AND SErvIcE 9.2.2 check air gap The brakes are delivered ex works with pre-set air gap X (nominal air gap) ready for installation. As a result of wear, the air gap increases. To ensure proper functioning, the air gap (distance between magnet housing on lining) needs to be checked in regular intervals in energized state with dial gauge (measuring bridge). -
Page 38: Replacing The Lining
MAINTENANcE AND SErvIcE Figure 16: Checking the air gap Furthermore, the teeth of the lining and the hub must be checked. Worn parts must be replaced. 9.2.3 replacing the lining cAUTION Loss of braking efficiency! Securing the load! ► Prevent damage to the hub by all means. ►... -
Page 39: Check The Function Hand Release (Option)
MAINTENANcE AND SErvIcE 9.2.4 check the function hand release (option) This section describes the subsequent check of the optional hand release on the brake. Note! The type of hand release attachment to the brake may vary depending on the ordered design and size of the brake Size Adjustment dimen-... -
Page 40: Dismounting And Disposal
DISMOUNTING AND DISPOSAL 10 Dismounting and Disposal 10.1 Dismounting For dismounting the brake => „9.2.1 Dismount the brake“). 10.2 Disposal Note! Separated according to the materials used, dispose of the electromagnetic brake com- ponents in compliance with the applicable local environmental regulations. The corresponding key numbers are subject to change depending on the disassembling process (metals, plastics and cables). -
Page 41: Certification
11 Certification 11.1 EU Declaration of conformity Document No. / month.year: ce_mt_rns-mt-h_en / 01.2019 Manufacturer: KEB Automation KG Südstraße 38 32683 BARNTRUP Germany Product type: spring applied fail safe brake COMBISTOP permanent magnet - brake COMBIPERM electromagnet – clutch and... - Page 42 Zertifizierungsstelle des RWTÜV Steubenstrasse 53 D - 45138 Essen No. of approval 041 004 500 Dated: 20.10.1994 Valid until: December 2021 KEB Automation KG, Südstr. 38, D-32683 Barntrup www.keb.de E-Mail: info@keb.de Tel.: +49 5263 401-0 Fax: -116 Seite: 2 von 2...
-
Page 43: Csa Certificat
Project: 70199031 Date Issued: 2018-10-05 Issued to: KEB Automation KG Suedstrasse 38 32683 Barntrup, GERMANY The products listed below are eligible to bear the CSA Mark shown with adjacent indicators 'C' and 'US' for Canada and US or with adjacent indicator 'US' for US only or without either indicator for Canada only. - Page 44 cErTIfIcATION Certificate: Master Contract: 172220 70199031 Project: Date Issued: 2018-10-05 70199031 Notes: 1. The first two figures define the size of the product. The next two figures describe the product type, e.g. COMBISTOP. The following three figures describe the design and the last four figures describe the layout of the product type.
- Page 45 cErTIfIcATION Supplement to Certificate of Compliance Certificate: Master Contract: 172220 (049670_0_000) 1267150 (LR49670) The products listed, including the latest revision described below, are eligible to be marked in accordance with the referenced Certificate. Product Certification History Project Date Description 70199031 2018-10-05 Update of report to cover correction of issued address and to update report in accordance with CSA-C22.2 No.
-
Page 46: Revision History
rEvISION HISTOrY 12 revision History version Date Description 2011-09 First edition 2019-10 Complete editorial revision... - Page 47 CEP 13569-430 Portal do Sol, São Carlos Brazil Gangnam Gu 135- 757 Seoul Republic of Korea Tel: +55 16 31161294 E-Mail: roberto.arias@keb.de Tel: +82 2 6253 6771 Fax: +82 2 6253 6770 E-Mail: vb.korea@keb.de KEB Automation GmbH czech republic KEB RUS Ltd.
- Page 48 Automation with Drive www.keb.de KEB Automation KG Suedstrasse 38 32683 Barntrup Tel. +49 5263 401-0 E-Mail: info@keb.de...
