The hardware and software described in this document are products of KEB. The infor- mation contained in this document is valid at the time of publishing. KEB reserves the right to update this document in response to misprints, mistakes or technical changes.
The customer may use the instructions for use as well as further documents or parts from it for internal purposes. Copyrights are with KEB and remain valid in its entirety. This KEB product or parts thereof may contain third-party software, including free and/ or open source software.
TABLE OF CONTENTS Table of Contents Preface ..............................3 Signal words and symbols ......................3 More symbols ..........................3 Laws and guidelines ........................4 Warranty and liability ........................4 Support ............................4 Copyright ............................4 Table of Contents ........................... 5 List of Figures ............................6 List of Tables ............................
LIST OF FIGURES List of Figures Figure 1: Shield connection braket control unit 00F6V80-2000 for F6 housing 2 and 3 ....9 Figure 2: Shield connection braket power unit 00F6V80-2001 for F6 housing 2 built-in version ..10 Figure 3: Shield connection braket power unit 00F6V80-2002 for F6 housing 2 push-through version ..........................
PRODUCT DESCRIPTION 1 Product Description These instructions for use describe the mounting kits of the shield connection brakets for the COMBIVERT F6 series. These instructions for use are only valid in conjunction with the corresponding F6 power unit manual. 1.1 Scope of delivery of the mounting kits 1.1.1 Scope of delivery mounting kit control unit F6 housing 2 and 3...
PRODUCT DESCRIPTION 1.1.4 Scope of delivery mounting kit power unit for F6 housing 3 Type Description Number Screw Oval-head screw M3 x 12 Screw Oval-head screw M5 x 12 Screw Oval-head screw M6 x 20 Screw Oval-head screw M6 x 30 Cage nut M6 Clamp Shield clamp R10...
SHIELD CONNECTION BRAKET CONTROL UNIT FOR F6 HOUSING 2 AND 3 2 Dimensions 2.1 Shield connection braket control unit for F6 housing 2 and 3 Mounting kit 00F6V80-2000 Dimensions All dimensions in mm Figure 1: Shield connection braket control unit 00F6V80-2000 for F6 housing 2 and 3...
SHIELD CONNECTION BRAKET POWER UNIT FOR F6 HOUSING 2 BUILT-IN vERSION 2.2 Shield connection braket power unit for F6 housing 2 built-in version 3x45° Mounting kit 00F6V80-2001 Dimensions All dimensions in mm Figure 2: Shield connection braket power unit 00F6V80-2001 for F6 housing 2 built-in version...
SHIELD CONNECTION BRAKET POWER UNIT FOR F6 HOUSING 2 PUSH-THROUGH vERSION 2.3 Shield connection braket power unit for F6 housing 2 push-through version 3x45° Mounting kit 00F6V80-2002 Dimensions All dimensions in mm Figure 3: Shield connection braket power unit 00F6V80-2002 for F6 housing 2 push-through version...
SHIELD CONNECTION BRAKET POWER UNIT FOR F6 HOUSING 3 2.4 Shield connection braket power unit for F6 housing 3 Mounting kit 00F6V80-3001 Dimensions All dimensions in mm Figure 4: Shield connection braket power unit 00F6V80-3001 for F6 housing 3...
SHIELD CONNECTION BRAKET POWER UNIT FOR F6 HOUSING 4 2.5 Shield connection braket power unit for F6 housing 4 Mounting kit 00F6V80-4001 Dimensions All dimensions in mm Figure 5: Shield connection braket power unit 00F6V80-4001 for F6 housing 4...
ExEMPLARy ASSEMBLED SHIELD CONNECTION BRAKET 2.6 Exemplary assembled shield connection braket The following figure shows an example of an assembled shield connection braket for F6 housing 4. Figure 6: Exemplary assembled shield connection braket for F6 housing 4...
REqUIRED TOOL 3 Mounting 3.1 Required tool • Phillips screwdriver type PH1 • Phillips screwdriver type PH2 • Wrench for M4 • Wrench for M6 3.2 Tightening torques for the mounting on drive converter The shield connection brakets must be attached to the drive converter with the following torques.
MOUNTING OF A SHIELD CONNECTION BRAKET 3.3 Mounting of a shield connection braket Figure 7: Mounting of a shield connection braket Example F6 housing 2 push-through version ► Attach the shield connection braket and the supplied nuts / screws Figure 8: Attached shield connection braket Example F6 housing 2 push-through version ►...
MOUNTING OF A SHIELD CONNECTION BRAKET Figure 9: Shield connection braket mounted on the drive converter. Shield connection braket mounted on the drive converter.
REvISION HISTORy 4 Revision History version Date Description 2020-02 Completion of series version. 2020-11 Change of the measurments of 00F6V80-2000. 2021-04 Corrections to drawing 00F6V80-2000. 2022-01 Cover picture adapted. Number of clamps for kit 00F6V80-2000 adapted. 2022-03 M6 x 40 screws included in mounting kit 00F6V80-4001.
