3.2.1 Fieldbus interfaces
3.2.2 Ethernet protocols
ma_ca_c6-compact3-inst-20372037_en
C6 COMPACT 3
Program memory
Data storage
Material number
X1 socket RJ45
EtherCAT
master 100 Mbit/s
X2 socket RJ45
• Ethernet TCP/IP for diagnostics, configuration, update, HMI server and IIOT, 10/100
Mbit/s
X3 socket RJ45 (variant-dependent)
• Ethernet TCP/IP for diagnostics, configuration, update, HMI server and IIOT,
10/100/1000 Mbit/s
X10 socket D-Sub DE9 (variant-dependent)
• INTERBUS-IN
X11 socket D-Sub DE9 (variant-dependent)
• INTERBUS-OUT
X6 terminal block Push-in terminals (variant-dependent)
• Power Supply; no fielbus (4 pole)
• Power Supply + CAN (8 pole)
• Power Supply + CAN + RS485 (12 pole)
• Power Supply + CAN + RS232 (16 pole)
• DHCP
• DNS
• NTP
• FTP
• FTPS
• SNMP
• HTTP
• HTTPS
• SSH
Product description | 3
Model 1
Model 2
32 MB (CODESYS V3)
128 MB (CODESYS V3)
00C6BE1-1
00C6BE1-1
001
002
Model 3
Model 4
INTERBUS
00C6BE1-1
00C6BE1-2
004
001
Optional
variants
upon re-
quest
15
