6.2 Voltage supply
NOTICE
6.2.1 Terminal block X5
ma_ca_c6-compact3-inst-20372037_en
Use of suitable voltage sources!
Electric Shock!
a) Only voltage sources with safe safe extra-low voltage in accordance with
60364-4-41
may be used.
b) Ensure that the used voltage supplies have the appropriate overvoltage cat-
egory for the application.
c) The requirements listed for
complied with.
d) With existing or newly-wired circuits the person installing the device or machine
must ensure that the
PELV
e) Connections with higher voltages must be excluded.
Voltage supply occcurs via terminal block X5.Depending on the variant, a 4-, 8-,
12- or 16-pole pluggable terminal block is used.
X5
2
4
1
3
2
4
6
8
1
3
5
7
Electrical installation | 6
SELV
and
PELV
circuits in
requirements are met.
PIN
Designation Notes
1
24V
DC 24 V supply voltage
(internally connected to
pin 3)
2
0V
Reference potential to
24 V (internally connected
to pin 4)
3
24V
DC 24 V supply voltage
(internally connected to
pin 1)
4
0V
Reference potential zu
24 V (internally connected
to pin 2)
5-8
-
(≡►
9-12
-
(≡►
13-16 -
(≡►
HD
HD 60364-4-41
must be
CAN
[} 35])
RS485
[} 37])
RS232
[} 38])
31
