6 Electrical installation
NOTICE
6.1 Assembly of wires
NOTICE
30
Ensure line protection by triggering the fuse!
a) The supply voltage must be able to supply fourfold of the rated current of the
internal fuse (4 A).
b) If a smaller power supply is used depending on the application, the device must
be protected with an external fuse.
• Lay control and power cables separately (approx. 10...20 cm distance).
• Lay power cable crossings at right angles.
• The following measures can be taken to prevent electromagnetic interferences:
– Always connect the shielding with the greatest possible surface.
– Position the shield as close as possible to the terminal.
– Always use twisted and shielded cables for analog control cables. Connect
shielding to source on one side only.
– Twist digital control cables. Shielding may be required from 3 m. In this
case, place on both sides.
• The device is protected against reverse polarity of the input voltage.
• The 24 V supply must not fall below or exceed the input voltage range specified
in the technical data, independent of the operating conditions.
• If power interruptions need to be bridged, an external
Loose and slack cable connections!
Malfunctions due to loose contacts.
a) Observe metal sleeve length and stripping length according to table.
b) Use a suitable pressing tool.
c) Make sure that all wires are inserted into the wire-end sleeve.
d) After inserting the cable into the terminal, check that it is firmly seated.
Cross section Wire end ferrule
0.5...1 mm² With plastic collars
(20...17 AWG)
0.5...1,5 mm² Without plastic collars
(20...16 AWG)
0.2...1.5 mm² Without wire end fer-
(24...16 AWG) rule
Solid or fine strand
Tab. 1: Wire end ferrules and stripping length
KEB Automation KG
UPS must be used.
Metal sleeve Stripping
length length
10 mm 12 mm
10 mm 10 mm
- 10 mm
