- Page 1 COMBISTOP T INSTRUCTIONS FOR USE | INSTALLATION TYPE 28 Translation of the original manual Document 20193433 EN 03...
-
Page 3: Preface
PrEfAcE Preface The described devices or add-on parts are products of the KEB Automation KG. The enclosed documents correspond to conditions valid at printing. Misprint, mistakes and technical changes reserved. Signal words and symbols Certain operations can cause hazards during the installation, operation or thereafter. -
Page 4: Laws And Guidelines
The customer may use the instructions for use as well as further documents or parts from it for internal purposes. Copyrights are with KEB Automation KG and remain valid in its entirety. Other wordmarks or/and logos are trademarks (™) or registered trademarks (®) of their... -
Page 5: Table Of Contents
3.1 Operating conditions ........................19 3.1.1 Climatic environmental conditions ..................19 3.1.2 Electrical operating conditions .................... 19 3.2 Device data cOMbISTOP T Type 28 ..................... 20 3.2.1 Overview ..........................20 3.3 Dimensions and weights ......................21 3.3.1 Version without options ...................... 21 3.3.2 Dimensions shaft sealing ring .................... - Page 6 TAbLE Of cONTENTS 4 Mounting ............... 25 4.1 Notes on mounting ........................25 4.1.1 Inspections to be done prior to mounting the brake ............25 4.1.2 Observe during mounting ....................26 4.2 Mounting the brake ........................26 4.2.1 Step 1: Installing the hub ....................27 4.2.2 Step 2: Mounting the lining ....................
- Page 7 TAbLE Of cONTENTS 9 Maintenance and service ..........42 9.1 Maintenance intervals ........................42 9.2 Service ............................42 9.2.1 Dismount the brake ......................42 9.2.2 Check air gap ........................43 9.2.2.1 Checking the air gap X ....................44 9.2.3 Replacing the lining ......................45 9.2.4 Check the function hand release (option) ................
-
Page 8: List Of Figures
Ambient temperature ....................... 19 Table 3: Construction and degree of protection ................19 Table 4: Device classification......................19 Table 5: Device data COMBISTOP T Type 28 ................20 Table 6: Pre-assembled connection cables ................... 34 Table 7: Run in of the brake......................39 Table 8: Troubleshooting .......................41... -
Page 9: Glossary
Functional earth Reference potential, ground International standard IP xx Degree of protection (xx for level) KEB product The KEB product is subject of this manual. Manufacturer The manufacturer is KEB, unless otherwise specified (e.g. as ma- nufacturer of machines, engines, vehicles or adhesives). -
Page 10: Standards For Mechanical Components
STANDArDS fOr MEcHANIcAL cOMPONENTS Standards for mechanical components VDE 0580 Electro magnetic devices and components DGUV regulation 3 Electrical installations and equipment DIN 46228-1 Tubular end-sleeves without plastic sleeve DIN 46228-4 Tubular end-sleeves with plastic sleeve DIN IEC 60364-5-54 Low-voltage electrical installations - Part 5-54: Selection and erection of electrical equipment - Earthing arrangements, protective conductors and protec- tive bonding conductors EN 60204-1... -
Page 11: Basic Safety Instructions
NOTICE Hazards and risks through ignorance. ► Read the instructions for use ! ► Observe the safety and warning instructions ! ► If anything is unclear, please contact KEB ! 1.1 Target group This manual is determined exclusively for technical staff. Technical staff for the purpose of this manual must have the following qualifications: • Knowledge and understanding of the safety instructions. -
Page 12: Installation And Mounting
bASIc SAfETY INSTrUcTIONS 1.3 Installation and mounting NOTICE Squeezing and pinching of fingers by self-rotation. ► Before installation, make sure that the drive is load-free. ► Secure drive against rotation. Consider the following installation measures to prevent faults ► Do not operate the brake in an explosive environment. ►... -
Page 13: Start-Up And Operation
bASIc SAfETY INSTrUcTIONS 1.5 Start-up and operation The operation must not be started until it is determined that the installation complies with the machine directive; Account is to be taken of 60204-1. cAUTION Pay attention to friction work (speed and the frequency of operation) ! Loss or drop of the braking torque ! ►... -
Page 14: Maintenance
bASIc SAfETY INSTrUcTIONS 1.6 Maintenance ► Secure the brake against being switched on accidentally during maintenance work. ► Make the brake load-free during maintenance work to avoid uncontrolled move- ments. ► Protection against the ingress of foreign particles into the air gap. These particles may impede the movement of the armature. -
Page 15: Product Description
Any use beyond the technical specifications is also considered as not specified. The actual use of the brake in the target products is beyond KEB Automation KG's con- trol and, therefore, shall be exclusively within the operating company's responsibility. -
Page 16: Type Code
PrODUcT DEScrIPTION 2.4 Type code The type designation and the version can be found on the nameplate or on the marking. x x 2 8 G x x - x x x x Version Customer versions completely closed Housing for tacho mounting W: Shaft sealing ring 1: without hand release hand release... -
Page 17: Overview/Parts List
PrODUcT DEScrIPTION 2.5 Overview/Parts List Legend Size 02 to 06 Seal ring Size 07 to Magnetic system Lining Magnet Flange (optional) Adjusting spacer Seal ring Armature Hand release (optional) Figure 1: Parts list COMBISTOP Type 28... -
Page 18: Functional Description
PrODUcT DEScrIPTION 2.6 functional description The braking force is generated in de-energised state by pressure springs which press the armature and the lining against the friction surfaces. The lining is twist-proof but can be axially moved while connected to the shaft. After applying the rated voltage, the coil inside the magnet creates a magnetic field which attracts the armature against the spring force. -
Page 19: Technical Data
3 Technical data 3.1 Operating conditions 3.1.1 climatic environmental conditions Operation Standard class Notes - 5...60°C (standard) Ambient temperature – VDE 0580 - 40...60°C (CCV: Cold Climate Version) Table 2: Ambient temperature Operation Standard Installation situation class Notes On free machine wall without IP66 hand release On free machine wall with... -
Page 20: Device Data Combistop T Type 28
DEvIcE DATA cOMbISTOP T TYPE 28 3.2 Device data cOMbISTOP T Type 28 3.2.1 Overview Device size Characteristic torque / Nm Rated power Rated voltage 24 / 105 / 180 / 205 N_dc Cyclic duration factor c.d.f. / % Speed for service braking... -
Page 21: Dimensions And Weights
DIMENSIONS AND WEIGHTS 3.3 Dimensions and weights 3.3.1 version without options 07…0928G10-xxxx 02…0628G10-xxxx Dimensions / mm Weight / kg Size 28.G1 28.G2 max. 72 15 1-1.5 88x3 118 90 2-2.5 42.8 41.8 110x3 143 112 2-2.5 52.8 51.8 132x3 61.5 0.2 165 132 30 2.5-3 58.3 57.3 152x3... -
Page 22: Dimensions Shaft Sealing Ring
DIMENSIONS AND WEIGHTS 3.3.2 Dimensions shaft sealing ring for shaft sealing ring with shaft sealing ring Dimensions / mm Size Figure 4: Dimensions shaft sealing ring... -
Page 23: Version With Hand Release
DIMENSIONS AND WEIGHTS 3.3.3 version with hand release 02-05/0728G2x-xxxx 06/0828G2x-xxxx 0928G2x-xxxx Dimensions / mm Size 105.5 53.5 15.5 500 +15/-5 18.5 500 +15/-5 25.5 500 +15/-5 30.5 500 +15/-5 500 +15/-5 750 ±15 76.3 750 ±15 69.5 750 ±15 Figure 5: Version with hand release... -
Page 24: Version For Tachometer
DIMENSIONS AND WEIGHTS 3.3.4 version for tachometer xx28GxT-xxxx Dimensions / mm Size 41.8 51.8 57.3 67.8 73.2 85.5 Figure 6: Version for tachometer... -
Page 25: Mounting
MOUNTING 4 Mounting Unless otherwise stated, the numbers mentioned in this chapter refer to => „Figure 1: Parts list COMBISTOP Type 28“. 4.1 Notes on mounting 4.1.1 Inspections to be done prior to mounting the brake Before mounting the brake, check the following: ► Compliance of the ordered voltage and performance data with the type plate data. ►... -
Page 26: Observe During Mounting
MOUNTING 4.1.2 Observe during mounting During mounting, please observe the following notes/instructions: ► The friction surfaces of the brake must not come into contact with oil, grease, water or other fluids. Any contamination will result in loss of torque. ► Never use aggressive fluids (for example, cleaning agents) or the like to clean the brake. ► When mounting the hub and the magnetic system, the teeth of the hub and the lining must not be damaged. -
Page 27: Step 1: Installing The Hub
MOUNTING 4.2.1 Step 1: Installing the hub ► Mount the hub on the motor shaft. ► Secure the hub axially on the motor shaft. ► The hub and the linings must not be damaged! ④ ② ③ ① Legend Motor shaft Retaining ring Lining Figure 7:... -
Page 28: Step 2: Mounting The Lining
MOUNTING 4.2.2 Step 2: Mounting the lining ► Slide the lining onto the hub. ► While doing so, be careful not to damage the lining by misaligned or tilted positioning. ► The lining must be easily movable on the hub. Legend Motor shaft Retaining ring... -
Page 29: Check Air Gap X
MOUNTING ① ② Legend Motor shaft Magnetic system Figure 10: Mounting the magnetic system Notes to the socket head screws For fastening the magnetic system, we recommend socket head screws of strength class 8.8, which should be tightened with the tightening torques rec- ommended by the manufacturer. -
Page 30: Micro Switch (Option)
MOUNTING 4.3 Micro switch (option) A microswitch can only be retrofitted if the brake is prepared for it. That is why the variant must be ordered already ex factory. The microswitch can be used for armature position monitoring or as wear control. 4.3.1 Microswitch as armature position monitoring (default setting) A micro switch can be used to monitor the switching state of the armature (brake open/ closed). -
Page 31: Adjustment And Change Of The Microswitch
MOUNTING 4.3.3 Adjustment and change of the microswitch NOTICE Unauthorized exchange, repair and modifications! Adjustment and change of the microswitch may only be carried out by qualified personnel! cAUTION Loss of braking efficiency! Before replacing the microswitch, mechanically secure the load against unintended movements and disconnect the brake from load! Legend Micro switch... -
Page 32: Dismounting
MOUNTING 4.3.3.1 Dismounting ► Remove the two socket head screws. ► Remove the microswitch. 4.3.3.2 Mounting ► The micro switch is mounted in reverse order. ► Connect the micro switch according to the following connection diagram: 4.3.3.3 Connecting the microswitch Connect the micro switch as a normally open contact (terminal 1 and 4). -
Page 33: Adjustment Of The Microswitch
MOUNTING 4.3.3.4 Adjustment of the microswitch cAUTION Loss of braking efficiency! Before checking the micro switch settings, mechanically secure the load against unintended movements and disconnect the brake from load! ① ④ ② ③ Legend Microswitch Socket head screw Hexagon head screw Hexagon nut Figure 13: Adjustment of the microswitch... -
Page 34: Electrical Connection
► Compare with existing voltage source. ► The maximum input voltage U must not be exceeded. ► Only connect if the values match. If no suitable DC voltage is available, the following KEB accessories can be used: • Half and full-wave rectifier (COMBITRON 91) •... -
Page 35: Ac Side Switching
ELEcTrIcAL cONNEcTION NOTICE connection for drive controller operation. ► Rectifiers or power boxes are destroyed when operated on drive controllers. ► Rectifiers or power boxes may only be connected directly to the mains. Influence on the connection time ! The brake can be switched off on the DC side or on the AC side. Switching off on the DC side reduces the connection time, i.e. the period of time until the torque is reached to decelerate. 5.1.1 Ac side switching 5.1.1.1 Connection for AC side switching ①... -
Page 36: Connection In The Terminal Box For Ac Side Switching
ELEcTrIcAL cONNEcTION 5.1.1.2 Connection in the terminal box for AC side switching ① Legend Jumper Figure 15: Connection in the terminal box for AC side switching • Not permitted for drive controller operation, since the power box or the rectifier would be destroyed. -
Page 37: Dc Side Switching
ELEcTrIcAL cONNEcTION 5.1.2 Dc side switching Switching occurs between rectifier and brake. KEB rectifiers and power boxes are pro- tected against the voltage peaks resulting from the switching. Figure 16: Connection for DC side switching • Not permitted for drive controller operation, since the power box or the rectifier would be destroyed.. -
Page 38: Dc And Ac Side Switching
ELEcTrIcAL cONNEcTION 5.1.3 Dc and Ac side switching Figure 17: Connection for DC and AC switching • Drive controller operation possible, because the power box or the rectifier is sup- plied from the mains. • For drive controller operation, switch the switch via digital output during ramp-up. • Enables the shortest switch-off times. • Reduces the contact erosion. 5.1.4 Protective earth The brake does not have its own PE connection. -
Page 39: Start-Up
INSPEcTIONS PrIOr TO STArT-UP Of THE brAKE 6 Start-up 6.1 Inspections prior to start-up of the brake 6.1.1 visual inspection • Do connection and rated voltage (magnet marking) agree? • Are external damages visible? • Are there impurities in the functional area or foreign bodies in the air gap of the brake? 6.1.2 Load-free testing •... -
Page 40: Operation
OPErATION 7 Operation The brake is switched via the voltage supply => brake“. The „5.1 Connection of the max. number of switching cycles must not be exceeded => „3.2 Device data COMBIS- TOP T Type 28“ 7.1 Hand release (option) As an option, the brake can be delivered with a hand release. -
Page 41: Troubleshooting
Magnet coil or connecting Replace the coupling. cable defective Install a high-speed circuit Excessive heating breaker (for example, KEB Pow- erbox). Damaged teeth impede Replace the lining and the hub. movement of armature No braking function Friction surfaces contam-... -
Page 42: Maintenance And Service
MAINTENANcE AND SErvIcE 9 Maintenance and service • Observe the general safety instructions. • The brake must not be under voltage during maintenance and repair work. • Protect electrical and electronic components from splash water. 9.1 Maintenance intervals Due to the design, the brake COMBISTOP Type 28 can only be checked when it is removed. -
Page 43: Check Air Gap
MAINTENANcE AND SErvIcE 9.2.2 check air gap The brakes are delivered ex works with preset air gap "X“ (nominal air gap) ready for installation. As a result of wear, the air gap increases. To ensure proper functioning, the air gap (distance between magnet housing on lining) needs to be checked in regular intervals in energized state with dial gauge (measuring bridge). -
Page 44: Checking The Air Gap X
MAINTENANcE AND SErvIcE 9.2.2.1 Checking the air gap X ► Connect the brake to rated voltage (the armature must be in contact with the magnet). ► The supply voltage can be found in the performance data on the type plate at the magnet or in the drawings. -
Page 45: Replacing The Lining
MAINTENANcE AND SErvIcE 9.2.3 replacing the lining cAUTION Loss of braking efficiency! Securing the load! ► Prevent damage to the hub by all means. ► Be careful not to damage the lining by misaligned or tilted positioning. ► The lining must not come into contact with cleaning agents or sol- vents. -
Page 46: Checking The Adjustment Dimension
MAINTENANcE AND SErvIcE 9.2.4.1 Checking the adjustment dimension The adjustment dimension 'm' must be checked/adjusted with attracted armature. The adjustment dimension applies to characteristic torque and operation with rated voltage. Figure 21: Adjustment dimension "m" of the hand release... -
Page 47: Dismounting And Disposal
DISMOUNTING AND DISPOSAL 10 Dismounting and disposal 10.1 Dismounting For dismounting the brake => „9.2.1 Dismount the brake“. 10.2 Disposal Separated according to the materials used, dispose of the electromagnetic brake components in compliance with the applicable local environmental regulations. The corresponding key numbers are subject to change depending on the disassembling process (metals, plastics and cables). -
Page 48: Certification
Size 01 up to 14 Voltage category 71...440Vdc ( 50 … 690 Vac) This declaration of conformity is issued under the sole responsibility of KEB Automation KG. The above given product is in accordance with the following directives of the European Union Number: Low voltage : 2014 / 35 / EU Text:... -
Page 49: Figure 22: Eu Declaration Of Conformity
Zertifizierungsstelle des RWTÜV Steubenstrasse 53 D - 45138 Essen No. of approval 041 004 500 Dated: 20.10.1994 Valid until: December 2024 KEB Automation KG, Südstr. 38, D-32683 Barntrup www.keb.de E-Mail: info@keb.de Tel.: +49 5263 401-0 Fax: -116 Seite: 2 von 2... -
Page 50: Csa Certificat
Project: Date Issued: 70199031 2018-10-05 Issued to: KEB Automation KG Suedstrasse 38 32683 Barntrup, GERMANY The products listed below are eligible to bear the CSA Mark shown with adjacent indicators 'C' and 'US' for Canada and US or with adjacent indicator 'US' for US only or without either indicator for Canada only. - Page 51 cErTIfIcATION Certificate: 70199031 Master Contract: 172220 Project: 70199031 Date Issued: 2018-10-05 Notes: 1. The first two figures define the size of the product. The next two figures describe the product type, e.g. COMBISTOP. The following three figures describe the design and the last four figures describe the layout of the product type.
-
Page 52: Figure 23: Csa Certificat
cErTIfIcATION Supplement to Certificate of Compliance Certificate: 1267150 (LR49670) Master Contract: 172220 (049670_0_000) The products listed, including the latest revision described below, are eligible to be marked in accordance with the referenced Certificate. Product Certification History Project Date Description 70199031 2018-10-05 Update of report to cover correction of issued address and to update report in accordance with CSA-C22.2 No. -
Page 53: Revision History
rEvISION HISTOrY 12 revision history version Date Description 2011-09 First edition 2019-10 Complete editorial revision 2023-11 Adaptation of designations and values... - Page 54 NOTES...
- Page 55 / Mitjer, Nave 8 - Pol. Ind. LA MASIA E-Mail: info@keb.cz Internet: www.keb.cz 08798 Sant Cugat Sesgarrigues (Barcelona) Spain Tel: +34 93 8970268 Fax: +34 93 8992035 E-Mail: vb.espana@keb.de Société Française KEB SASU france Z.I. de la Croix St. Nicolas 14, rue Gustave Eiffel...
- Page 56 Automation with Drive www.keb.de KEB Automation KG Suedstrasse 38 32683 Barntrup Tel. +49 5263 401-0 E-Mail: info@keb.de...
