2. SAFETY

2.1 Safety information

2.1.1 SAFETY MESSAGES

Warnings related to the safety of the user and of the equipment as envisaged in this document are as follows:
WARNING! Indicates a hazardous situation which, if not avoided, may cause death or serious injury.
NOTICE: indicates obligations that if not observed may cause harm to the equipment.
2.1.2 SAFETY SYMBOLS ON THE PRODUCT
This symbol marked on the product indicates that the manual must be consulted. In particular, pay
attention to the following activities:
wiring of the connections (see "Terminal blocks and connector pin-outs" on page 81 and "Electrical
l
connections" on page 83)
cable operating temperature (see "Terminal blocks and connector pin-outs" on page 81)
l
control unit cover, which was subjected to a low energy impact test (see "Technical data" on page 79)
l
2.1.3 PERSONNEL SKILLS
The recipients of this manual and the skills required for each activity presented herein are as follows:
Recipient
Machinery
l
manufacturer
Protection
l
system installer
l
l
Machinery
l
maintenance
technician

2.1.4 INTENDED USE

Inxpect Value Line is a human body detection system.
Depending on its model-type, each sensor performs one of the following protective functions:
Access detection function: access of one or more persons to a hazardous area deactivates the outputs to
l
stop the moving parts of the machinery.
Restart prevention function: prevents unexpected starting or restarting of the machinery. Detection of
l
motion within the dangerous area maintains the outputs deactivated to prevent machinery starting.
Stop signal: it forces all the outputs to OFF-state.
l
Restart signal: it enables the control unit to switch to ON-state the outputs related to all the detection
l
fields with no motion detected. It can be performed:
using single channel inputs/OSSDs
o
using dual channel inputs/OSSDs
o
Inxpect Value Line | Instruction manual v1.0 FEB 2025| Inxpect VL-IM-7_00375_en_v1.0 | © 2025 Inxpect SpA
Assignments
defines which protective devices should be
installed and sets the installation
specifications
installs the system
configures the system
prints configuration reports
performs maintenance on the system
Skills
knowledge of significant hazards of the
l
machinery that must be reduced
knowledge of the entire machinery safety
l
system and the system on which it is
installed
advanced technical knowledge in the
l
electrical and industrial safety fields
knowledge of the dimensions of the
l
dangerous area of the machinery to be
monitored
receives instructions from the machinery
l
manufacturer
advanced technical knowledge in the
l
electrical and industrial safety fields
