9.4 ERROR events (control unit)
9.4.1 Introduction
A diagnostic error is logged every time the periodic diagnostic functions detect a coming or going fault on the
control unit.
9.4.2 Temperature errors (TEMPERATURE ERROR)
Error
BOARD TEMPERATURE TOO LOW Board temperature below minimum
BOARD TEMPERATURE TOO HIGH Board temperature above maximum
9.4.3 Control unit voltage errors (POWER ERROR)
Error
Control unit voltage
UNDERVOLTAGE
Control unit voltage
OVERVOLTAGE
ADC CONVERSION
ERROR
The following table describes the control unit voltage:
Screen printing
VIN
V12
V12 sensors
VUSB
VREF
ADC
9.4.4 Peripheral error (PERIPHERAL ERROR)
Error detected by diagnostics relative to the micro-controller, its internal peripherals or memories.
9.4.5 Configuration errors (FEE ERROR)
Indicates that the system must still be configured. This message can appear when the system is first turned on or
after reset to default values. It can also represent another error on the FEE (internal memory).
9.4.6 Output errors (OSSD ERROR)
Error
OSSD 1 SHORT-
CIRCUIT
OSSD 2 SHORT-
CIRCUIT
OSSD 3 SHORT-
CIRCUIT
OSSD 4 SHORT-
CIRCUIT
OSSD 1 NO LOAD
OSSD 2 NO LOAD
OSSD 3 NO LOAD
OSSD 4 NO LOAD
Inxpect Value Line | Instruction manual v1.0 FEB 2025| Inxpect VL-IM-7_00375_en_v1.0 | © 2025 Inxpect SpA
Undervoltage error for the indicated voltage
Overvoltage error for the indicated voltage
ADC conversion error in the micro-controller
Power supply voltage (+24 V DC)
Internal supply voltage
Sensors power supply voltage
USB port voltage
Inputs reference voltage (VSNS Error)
Analog-digital converter
Short-circuit error on MOS output 1
Short-circuit error on MOS output 2
Short-circuit error on MOS output 3
Short-circuit error on MOS output 4
No load on OSSD 1
No load on OSSD 2
No load on OSSD 3
No load on OSSD 4
Meaning
Meaning
Description
Meaning
