11.1 Technical data

11.1.1 General specifications

Detection Inxpect motion detection algorithm based
method on FMCW radar
Frequency Working band: 24–24.25 GHz
Maximum radiated power: 12.6 dBm EIRP
(at +25° C)
Maximum radiated power: 16.5 dBm EIRP
(at -40° C)
Modulation: FMCW
Detection From 0 to 4 m
interval
Detectable 0.17 m 2
target RCS
CRT (Certified 10 s
Restart Timeout)
Guaranteed Access detection (if available): < 100 ms *
response time
Restart prevention (if available): 10 s
Total Max. 14 W (control unit and six sensors)
consumption
Electrical Polarity inversion
protections
Overcurrent through resettable integrated
fuse (max. 5 s @ 8 A)
Overvoltage II
category
Altitude Max. 2000 m ASL
Air humidity Max. 95%
Noise emission Negligible**
Note*: the value depends on the Electromagnetic
robustness level set through the Inxpect Safety
application, see "Electromagnetic Robustness" on
page 37.
Note**: the A-weighted emission sound pressure
level does not exceed 70 dB(A).
Inxpect Value Line | Instruction manual v1.0 FEB 2025| Inxpect VL-IM-7_00375_en_v1.0 | © 2025 Inxpect SpA
WARNING! During the
real-time validation and
the download of the log
file, the response time is
not guaranteed.

11.1.2 Control unit features

Outputs Configurable as follows:
4 Output Signal Switching Devices
l
(OSSDs) (used as single channels)
2 dual channel outputs
l
1 dual channel output and 2 Output
l
Signal Switching Devices (OSSDs)
High-side outputs (with extended
protection function)
Maximum current: 0.4 A
l
Maximum power: 11.2 W
l
The OSSDs provide what follows:
ON-state: from Uv-1V to Uv (Uv =
l
24V +/- 4V)
OFF-state: from 0 V to 2.5 V r.m.s.
l
OSSD Maximum resistive load: 100 KΩ
l
characteristic
Minimum resistive load: 70 Ω
l
Maximum capacitive load: 1000 nF
l
Minimum capacitive load: 10 nF
l
Inputs Configurable as follows:
4 single channel type 3 digital inputs
l
with common GND
2 dual channel type 3 digital inputs
l
with common GND
1 dual channel and 2 single channels
l
type 3 digital inputs with common GND
See "Voltage and current limits for digital
inputs" on page 81.
Power supply 24 V DC (20–28 V DC) *
Maximum current: 1 A
Consumption Max. 5 W
Assembly On DIN rail
Weight With cover: 170 g
Degree of IP20
protection
Terminals Section: 1 mm
Maximum current: 4 A with 1 mm
Impact test 0.5 J, 0.25 kg ball from a 20 cm height
Shock/Bump In accordance with IEC/EN 61496-1:2013
sec. 5.4.4.2 (IEC 60068-2-27)
Vibration In accordance with IEC/EN 61496-1:2013
sec. 5.4.4.1 (IEC 60068-2-6)
Pollution degree 2
Outdoor use No
Operating From -30 to +60 °C
temperature
Storage From -40 to +80 °C
temperature
Note*: it is recommended to supply the control unit
by an isolated power source which complies with
the standard IEC/EN 60204-1 and fulfils the
requirements of:
Limited-Energy Circuit in accordance with
l
IEC/UL/CSA 61010-1/ IEC/UL/CSA 61010-2-201
or
Limited Power Source (LPS) in accordance with
l
IEC/UL/CSA 60950-1
