3.4.3 Output configurations

The system installer can decide to configure the system as follows:
two dual channel outputs (e.g., Detection signal 1 and Detection signal 2)
l
one dual channel output (e.g., Detection signal 1) and two single channel output (e.g., System diagnostic
l
signal and Detection warning 2)
each output as a single output (e.g., Detection warning 2, System diagnostic signal, Muting enable
l
feedback signal and Restart feedback signal)
Note: configuring the system with only one channel output may result in serious injuries in case of an output circuit
fault and a failure of the machine to stop.
3.4.4 Dual channel output configuration
The dual channel output is automatically managed by the Inxpect Safety application and it only matches the
single OSSD outputs as follows:
OSSD 1 with OSSD 2
l
OSSD 3 with OSSD 4
l
3.4.5 Restart feedback signal option settings
If at least one detection field in use is configured as Manual restart (in Settings > Restart function), the behavior
of the Restart feedback signal depends on the option selected:
Option
Standard The selected output is activated (ON-state) if there is no more motion within at least one
l
detection field configured as Manual restart. The ON-state lasts as long as there is an absence
of motion within one or more detection fields (configured as Manual restart) and until the restart
signal is activated on the selected input.
The selected output remains in OFF-state if:
l
none of the detection fields (configured as Manual restart) are ready to be restarted, and as
o
long as a motion (or a fault) is detected within at least one detection field (configured as
Manual restart), or
as long as no motion is detected within any detection fields configured as Manual restart, but
o
none can be restarted yet.
Pulsed The selected output is activated (ON-state) if there is no more motion within at least one
l
detection field configured as Manual restart. The ON-state lasts as long as there is an absence
of motion within one or more detection fields (configured as Manual restart) and until the restart
signal is activated on the selected input.
The selected output switches continuously between ON-state and OFF-state if none of the
l
detection fields (configured as Manual restart) are ready to be restarted, and as long as a
motion (or a fault) is detected within at least one detection field (configured as Manual restart)
The selected output remains in OFF-state as long as no motion is detected within any detection
l
fields configured as Manual restart, but none can be restarted yet.
3.4.6 Detection signal/warning group settings
Each detection field of each sensor can be assigned to a group to associate them with the same output.
Through the Inxpect Safety application (in Settings > Detection field groups), each detection field of each
sensor can be associated with a group or both groups. By default, a detection field does not belong to any group.
WARNING! Consider the detection field dependency choice during the group's configuration. See
"Detection fields dependency and detection signal generation" on page 25
Example
It is possible to configure that the following detection fields belong to group 1:
- Detection field 1 of Sensor 1
- Detection field 1 of Sensor 3
- Detection field 2 of Sensor 1
By doing so, a specific output assigned to Detection signal group 1 or Detection warning group 1 will switch
to the OFF-state when a movement is detected in one of these detection fields.
