9. Troubleshooting
LED Status
S5 Steady red
S6 Steady red
All LEDs from Steady red
S1 to S4
together
At least one Flashing red
LED
At least one Flashing green See "Sensor LED" below
LED
All LEDs Steady orange -
All LEDs Flashing green
one after the
other in
sequence
All LEDs Off
All LEDs Off
Note: fault signal on the control unit (steady LED) takes priority over a faulty sensor signal. For the status of the
single sensor, check the sensor LED.
Note*: S1 is the first from the top.
Note**: S1 corresponds to the sensor with ID 1, S2 corresponds to the sensor with ID 2 and so on.

9.1.2 Sensor LED

Status Application messages
2 flashes * CAN ERROR
3 flashes * CAN ERROR
66
Application messages
CAN ERROR
FEE ERROR, FLASH
ERROR or RAM ERROR
SENSOR
CONFIGURATION ERROR
See "Sensor LED" below
-
In Dashboard > System
status icons
Progress icon
Problem
ID not assigned
Error in communication
with the control unit
Inxpect Value Line | Instruction manual v1.0 FEB 2025 | Inxpect VL-IM-7_00375_en_v1.0 | © 2025 Inxpect SpA
Problem
Communication Check connections of all
error with at least sensors in the chain starting
one sensor from the last sensor in error.
Check that all the sensors
have an assigned ID (in
Inxpect Safety Settings >
Node ID Assignment).
Configuration Reconfigure or configure the
saving error, system (see "Manage the
configuration not configuration" on page 62).
performed or
If the error persists, please
memory error
contact Technical Support.
Error during the Check the sensors connected
configuration of the and try again to perform the
sensors configuration of the system
via the Inxpect Safety
application.
Sensor Check the problem through
corresponding to the LED on the sensor.
the flashing LED in
error ** (see"Sensor
LED" below)
Sensor If the issue persists longer
corresponding to than one minute, please
the flashing LED in contact Technical Support.
error ** (see"Sensor
LED" below)
The system is Wait for a few seconds.
starting up.
The control unit is Open the latest available
in boot state. version of the Inxpect Safety
application, connect to the
device and proceed with the
automatic recovery
procedure.
If the issue persists, please
contact Technical Support.
Configuration not Configure the system.
yet applied to the
control unit.
Configuration Wait for the transfer to be
transfer to the completed.
control unit in
progress.
Assign a Node ID to the sensor (see
"Connect the sensors to the control unit"
on page 57).
Check connections of all sensors in the
chain starting from the last sensor in error.
Solution
Solution
