Level
Low
Disabled
The anti-masking function is disabled by default. To enable the function, in the Inxpect Safety application, click
Settings, then Anti-tampering and set the sensitivity level of the function.
6.3.6 Checks when the anti-masking function is disabled
When the anti-masking function is disabled, perform the following checks.
Protective function
Access detection
function
Restart prevention
function
6.3.7 When not enabling the function
The anti-masking function should not be enabled under the following conditions:
(For S188A-X3 sensors) The monitored area includes moving parts that stop in different and unpredictable
l
positions.
The monitored area includes moving parts that vary their position while the sensors are in muting.
l
The sensor is positioned on a part that can be moved.
l
The presence of static objects is tolerated in the monitored area (e.g., loading/unloading area).
l
6.4 Multi-control unit Synchronization (only all S188A-X3
sensors)
6.4.1 Introduction
The multi-control unit synchronization function is necessary when multiple Inxpect Value Line are sharing the
same area and it allows the interferences between their sensors to be removed using a time synchronization
signal.
Note: the function can be used only if all the sensors are S188A-X3.
Inxpect Value Line | Instruction manual v1.0 FEB 2025| Inxpect VL-IM-7_00375_en_v1.0 | © 2025 Inxpect SpA
Description
The sensor detects masking only if the
sensor occlusion is complete and the
objects are highly reflective (e.g., metal,
water) near the sensor.
The sensor does not detect changes in the
environment.
Note: it is recommended to enable the
function if it is needed to signal the
presence of objects that might impede
normal detection.
Schedule
Before each machinery restart
Each time the outputs are
deactivated
Example application
Installations on moving parts, where the
environment is changing continuously, but
where static objects may be near the sensor
(obstacles on the route).
See "When not enabling the function" below.
Remove any objects that obstruct the field of view of
the sensor.
Reposition the sensor according to the initial
installation.
6. Other functions
Action
