Note: if there are more than four control units, the control units with the same channel must have their
monitored areas as far from each other as possible.
2. Click Settings > Digital Input-Output and set the digital input-output as follows:
If the network topology is...
star
daisy chain (linear)
Note*: present only if the trigger source is internal.
3. Connect the cables on the I/O terminal blocks of the control unit. See "Electrical connections" on the next
page for more details.
Inxpect Value Line | Instruction manual v1.0 FEB 2025| Inxpect VL-IM-7_00375_en_v1.0 | © 2025 Inxpect SpA
And the control unit is...
master*
slave
master*
slave (except the last in the chain) 1. Configure one of the digital
slave (last of the chain)
6. Other functions
Then...
Configure two of the digital
outputs as Acquisition Trigger.
Configure one of the digital inputs
as Acquisition Trigger.
Configure two of the digital
outputs as Acquisition Trigger.
inputs as Acquisition Trigger
2. Configure two of the digital
outputs as Acquisition
Trigger.
Configure one of the digital inputs
as Acquisition Trigger.
