Daisy chain (linear) example
Internal trigger source (control unit Master) + 2 control units (Slaves)
In this example:
Control unit channel 0 (Master) has OSSD3 and OSSD4 configured as Acquisition Trigger.
l
Control unit channel 1 (Slave) has OSSD3 and OSSD4 configured as Acquisition Trigger, and Digital Input 1
l
configured as Acquisition Trigger.
Control unit channel 2 (Slave) has Digital Input 1 configured as Acquisition Trigger.
l

6.5 Electromagnetic Robustness

6.5.1 Electromagnetic robustness parameter
With the Electromagnetic robustness parameter, it is possible to increase the robustness of the system to
electromagnetic interference (e.g., due to sensors of different systems installed too close to each other or
problems on the CAN bus).
In the Inxpect Safety application in Settings > Advanced, the following levels of robustness can be set:
Standard (default)
l
High
l
Very High
l
WARNING! The parameter impacts the system response time for the access detection function.
According to the chosen level, the maximum guaranteed response time is 100 ms (Standard), 150 ms
(High), or 200 ms (Very High).
